Daewoo DPP-32F1BMB - 7 Noticeable Points While Assembling

-16-
7. Noticeable Point While Assembling
A. DPP-32F1BMB Inside Feature
B. LVDS connect (Module) C. Inlet Power Cable Fixing
LVDS Cable Ground
Fixation
D. Inlet Ground contact E. AV3 Cable Arrangement
Inlet GND contact point
AV3&LSpeakerFilterEMI
