-40-
10. Assembly list
No. PCB ASS'Y CODE ASS'Y NAME ASS'Y DESCRIPTION
1 48B5655E05 TRANSMITTER REMOCON R-55E05 (AAA)
2 PTACPWG405 ACCESSORY AS DPP-32F1BMB
3 4850Q00910 BATTERY R03/NN
4 5PZCA2009A FILTER EMI ZCAT2035-0930A
5 PTBCSHG388 COVER BACK AS DPX-32F1BMB
6 PTCACAG405 CABINET AS DPP-32F1BMB
7 485A102780 GLASS FILTER DFM3203PFN
8 4852335600 PANEL L SGCC T=1.5
9 7002400852 SCREW MACHINE TRS 4X8 MFZN BK 3CR
10 4852335700 PANEL R SGCC T=1.5
11 4852335800 PANEL B SGCC T=2.0
12 4853299400 BRKT STAND SGCC T=0.8
13 485A115070 SHIELDRON 10X45X2.0(T) CU+NI
14 4853299200 BRKT INLET FILTER SGCC T=1.5
15 4856815910 CLAMP WIRE EGI T0.4+TUBE+PIE 4.2
16 4853299100 BRKT SUPPORT SGCC T=1.5
17 4851D01901 PLATE TERMINAL CH A AS 3636601 + 5950901 (SP-900PF)
18 4853834500 FRAME SUPPORT R SGCC T=1.5
19 4853834600 FRAME SUPPORT B SGCC T=1.5
20 4853834400 FRAME SUPPORT L SGCC T=1.5
21 4854966001 BUTTON CH ABS BK
22 4852183300 COVER CH SGCC T=0.8
23 4859006661 CABLE LVDS 1001-31FC+1001-31FC+SP901X=350
24 5PZCA2009A FILTER EMI ZCAT2035-0930A
25 4850K01700 CORE FERRITE BNF-1130
26 4850K01700 CORE FERRITE BNF-1130
27 PTFMSJG405 MASK FRONT AS DPP-32F1BMB
28 PTSPPWG405 SPEAKER AS DPP-32F1BMB
29 PTFRCAG405 FRAME AS DPP-32F1BMB
30 PTSNSWG405 STAND AS DPP-32F1BMB
31 PTMPMSG405 PCB MAIN MANUAL AS DPP-32F1BMB
32 PTUNMSG405 PCB UNION MANUAL AS DPP-32F1BMB
33 4850M002PD MODULE PDP PDP32F1X031(32F1T031)
34 485AS00028 CTRL ASSY
35 485AS00029 XRLT ASSY Data LEFT BOARD
36 485AS00030 XRRT ASSY Data RIGHT BOARD
37 485AS00031 YSUS ASSY Y-SUS BOARD
38 485AS00032 ZSUS ASSY Z-SUS BOARD
39 485AS00033 AC Noisefilter
40 485AS00034 32F1 Lite-On PSU PSU
41 485AS00035 32F1 LGIT PSU PSU
