-8-
The Feature of Inside
3-3. Power Specification
1) Input and Environmental Requirement
2) Output Characteristics
3. Connector
Output
Name
Output
Typical
(V)
Variable
Voltage
Range(V)
Voltage
Tolerance
(%)
Output Current(A)
Ripple & Noise
(mVp-p)
Min. Typical Max.
STBY5V 5.0 - 0 1.2 1.7 100mVp-p
5Vsc 5.0 - 0.1 0.7 1.7 200mVp-p
9Vsc 9 - c0 0.3 0.5 200mVp-p
16Vsc 16 -
1
c0.03 1.3 2.2 500mVp-p
Environment Requirement Description
Operating Temperature Range 0to55Deg.
Operating Humidity Range 10 to 90%
Storage Temperature Range -20to70Deg.
Cooling system Convection
Input Requirement Description
Nominal Input Voltage AC100V to AC240V
Input Voltage Variation Range AC90V to AC264V
Nominal Frequency 50 /60 Hz
Frequency Variation Range 47Hz to 63Hz
Inrush Current 50A peak MAX.
NO. YW396-09V SMW250-15
1 5V AC-DET
2 GND RL_ON
3 Va VS_ON
4 GND 5V_MNT
5 GND M5V_ON
6 GND GND
7 NC GND
8 Vs 16Vsc
9 Vs 16Vsc
10 GND
11 9Vsc
12 GND
13 5Vsc
14 STBY5V
15 GND
P812 P814
