-41-
Assembly list
1 4850M006PD MODULE PDP PDP32F1X374(32F1T374)
2 485AS00090 CTRL ASSY
3 485AS00091 XRLT ASSY Data LEFT BOARD
4 485AS00092 XRRT ASSY Data RIGHT BOARD
5 485AS00093 YSUS ASSY Y-SUS BOARD
6 485AS00094 ZSUS ASSY Z-SUS BOARD
7 485AS00033 AC Noisefilter
8 485AS00034 32F1 Lite-On PSU PSU
9 485AS00035 32F1 LGIT PSU PSU
32F1B Panel
