-13-
Service Mode
5-6. Misc
Tst Ptrn AT shows five cycled patterns (white, black, red, green, blue) every 1 minute
automatically
Tst Ptrn MA shows five cycled patterns manually by pressing volume up key.
5-7. Panel
Function Tst Ptrn AT Tst Ptrn MA TV Auto Off Search Mode
Default Value Undefined Undefined On 60Hz
Function Sync Mode Bright Mode Power Mode Gamma Mode Panel Temp
Default Value AUTO 100% 100% 2.2N **.*
Panel Temp indicates the current temperature of the panel.
5-8. Reset
Level 1 - Resets all data in E
2
PROM other than HDCP key, EDID, RGB offset
and YPbPr offset of FrontEnd_1.
Level 2 - Resets all data in E
2
PROM other than the exception of Level 1 and
Pw338B_1.
Factory - Resets the data of auto search, language setting, time setting, and the
user menu values that could be reset by ‘Initialize’ function in
Feature mode.
