* DSB-123A/AH/PH PART LIST (INDOOR UNIT)
No PART CODE PART NAME Q,TY SPEC REMARK
1 3110400300 BODY 1 HIPS T2.0 (GY171A)
2 3110078100 MOTOR IDU ASSY 1 ASSY
3 3118003500 MOTOR IDU 1 RB13B(220V, 50/60V)
4 3106400400 BEARING PLASTIC ASSY 1 DSB-123A/AH/PH
5 3110046000 FAN CROSS FLOW ASS`Y 1 SAN+G.F 30% ¿100xL615
6 3113000400 HOLDER MOTOR L 1 HIPS T2.0
7 7172401211 SPECIAL SCREW 2 TT2 TRS 4*12 MFZN
8 3113000500 HOLDER MOTOR R 1 HIPS T2.0
9 7172401211 SPECIAL SCREW 1 TT2 TRS 4*12 MFZN
10 3114503300 PLATE EVAP. L 1 PP T2.0(GY176A)
11 7172401211 SPECIAL SCREW 2 TT2 TRS 4*12 MFZN
12 3110054100 EVAPORATOR 1 ASSY (3R-3C, FPI=1.5)
13 3113309800 PIPE ARTRON HOSE 1 O.D ¥Õ32 I.D ¥Õ20 T=6, F-PE
14 3118100500 PAN DRAIN 1 HIPS T2.0(GY176A)
15 7172401211 SPECIAL SCREW 2 TT2 TRS 4*12 MFZN
16 3103210010 HOSE DRAIN ASSY 1 ASSY
17 3108003910 MOTOR STEPPING 1 MP24GA
18 7141400811 SCREW TAPPING 2 T2 PAN M4x8 MFZN
19 3104301700 LED PCB ASS`Y 1
3110059400 DSB-123A
20 3110059410 CONTROL BOX ASS'Y 1 DSB-123AH
3110059420 DSB-123PH
21 3110504000 CONTROL BOX 1 HIPS T2.0 (BLACK)
22 3101204600 CLAMP POWER CORD 1 DA-4N
23 7172401211 SPECIAL SCREW 1 TT2 TRS 4*12 MFZN
24 3111200800 CLAMP WIRE 1 HIPS T2.0 (BLACK)
25 7172401211 SPECIAL SCREW 1 TT2 TRS 4*12 MFZN
26 3111312110 POWER CORD ASSY 1 DSB-123A/AH
3111312115 DSB-123PH
27 3114503900 PLATE EARTH 1 SGCC T1.0x26xP46
28 3102702201 HARNESS TH3-1 1
29 3112716000 HARNESS 4W SIGNAL 1 DSB-123AH/PH
30 3112715900 HARNESS MOTOR SIGNAL 1
31 3112716100 HARNESS LED PCB 1
32 3112715800 HARNESS COMP SIGNAL 1
33 3112716250 HARNESS I/D EARTH 1 GREEN/YELLOW
34 3104896300 SENSOR I/D ASSY 1
35 3113700900 VOLTAGE GENERATOR 1 5.6KV DSB-123PH
36 3118900200 TERMINAL BLOCK 1 JXO-CH-2P DSB-123A
3108914200 1 JXO-CH-4P DSB-123AH/PH
37 7111301611 SCREW TAPPING 2 T1S PAN 3x16 MFZN
