NO PART CODE PART NAME Q'TY SPEC RE MARK
1 3100506900 CONTROL BOX 1 ABS
2 3104300730 CONTROL PCB ASS’Y1
3 3104397170 POWER PCB ASS’Y1
4 3104395300 SWITCH PCB ASS’Y1
5 3104395400 LED PCB ASS’Y1
6 3108004310 MOTOR STEPPING 1 DC 12V L=1300mm
7 3108004300 MOTOR STEPPING 2 DC 12V L=400mm
8 3108912330 TERMINAL BLOCK 1 SN-DBW-6P
9 5EPV633110 TRANSFORMER 1 DWA220V 50Hz
10 3106900210 CAPACITOR I.D.M 1 SH.M.B 1.2µF/450V
11 3104896000 SENSOR ID ASS’Y 1 PEM-KD43C-D1
12 3111322115 POWER CORD ASSY 1 220V 50Hz
13 3102704410 HARNESS COMP SIGNAL 1 UL1015 #18
14 3102704510 HARNESS LED PCB 1 UL1007 #24
15 3102704900 HARNESS CONNECTING 1 UL1007 #24
16 3102707000 HARNESS SWITCH PCB 1 VSF 12/0.16
17 3102797910 HARNESS EARTH 1 I/D EARTH
18 3102704420 HARNESS 4W 1 UL1015 #18
19 3114600400 FILTER POWER 2 1
20 3114600500 FILTER PCB 2 1
21 3114600600 FILTER SENSOR 2 1
22 3113701200 VOLTAGE GENERATOR 1
✔ Caution:
In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
