Daewoo DSB-092A - DSB-123 A Control Box Exploded View

127
No PART CODE PART NAME Q'TY SPEC REMARK
1 3100041750 BASE PAN PAINT ASSY 1 PAINTING
2 310P30281A FOOT CUSHION 4 NBR (54*63.5)
3
3100068201
COMPRESSOR ASSY
1
AWG5530EXC
DSB-240AH-R/240PH-R
3100068300 AWG5524EXN DSA-240AH-R
4 7400208411 WASHER PLAIN 3 ID8.4*OD22*T1.6
5 7392801211 NUT LOCK 3 M8*1.25P
6 3100078000 CONDENSER ASSY 1 AL+CU
7 3100082900 PIPE CAPILLARY ASSY 1 C1220T H/P
8 3100082800 PIPE REVERSING ASSY 1 C1220T-O
9 3102402100 GRILLE COND 1 PE
10 3100041100 GUIDE POST P/T ASSY 1 PAINTING
11
3100041200 DSB-240AH-R/240PH-R
3100041201
BRK SERVICE P/T AS 1 PAINTING
DSA-240AH-R
12 3105401800 SERVICE VALVE (G) 1 Ø15.88 (5/8”)
13 3105401200 SERVICE VALVE (L) 1 Ø9.52 (3/8”)
14 3106002300 BOLT HEX 4 M6*L20 MFZN
15 3100031702 PLT PARTITION ASSY 1 SGCC-M-Z22
16 3100088500 ASSY PANEL CONTROL 1 SGCC-M-Z22 T0.8 H/P
16-1 3104201601 PANEL CONTROL 1 SGCC-M-Z22 T0.8
16-2
3108912410
TERMINAL BOLCK 1
30A-3P
3108912330 SN-DBW-6P
16-3
3101202600 DA-4N DSB-240AH-R/240PH-R
3101202000
CLAMP CORD 1
NYLON66, (VDE) DSA-240AH-R
16-4
3109504830
CAPACITOR DUAL 1
5/45µF 400VAC
DSB-240AH-R/240PH-R
3109504820 5/35µF 400VAC DSA-240AH-R
16-5 3101203300 CLAMP CAPACITOR 1 SGCC Ø63 T0.8
16-6 5SC0202700 POWER RELAY 1 G7L-2A-TUB, 220/240V 50/60H
16-7 3104303110 PCB DICER ASSY 1 DSA-240AH-R/DSB-240AH-R
16-8 3115401800 VALVE AIR SOLENOID 1 220V 50Hz DSA-240AH-R/DSB-240AH-R
16-9 3118701800 TERMINAL BLOCK JOINT 1 DA-TB3 300V 20A
16-10 3110020100 ASSY FILTER SILENCER 1 MIDIUM+AT CB+PREE
16-11 3118800100 TERMINAL BLOCK 1 DA3P 300V 20A PBT (GLASS20~30%)
17 3105300400 SUPPORT MOTOR 1 SGCC-M-Z22 T1.6
18
3108009900
MOTOR ODU 1 OSME986DERC 230/50
DSB-240AH-R/240PH-R
9108005800 DSA-240AH-R
19 7348602011 BOLT HEX 4 WAS M6*L20 MFZN
20 3101802000 FAN PROPELLER 1 ABS+G/F(20%)
21 3100031400 CABINET FRONT P/T AS 1 PAINTING
22 3100031500 CABINET SIDE P/T AS 1 PAINTING
23 3100041500 PANEL TOP P/T ASSY 1 PAINTING
24 3102102000 GRILLE DISCHARGE 1 (BE-002D)
25 3100089200 SERVICE COVER ASSY 1 ASA
26 3111901900 FILTER MEMBRANE 1 D54.5 X L126
DSA-240AH-R/DSB-240AH-R
27 3117101210 COMP AIR 1 6.5LPM 230V/50Hz DSA-240AH-R/DSB-240AH-R
28 3110019910 ASSY FILTER AUTO 1 10UM AUTO DSA-240AH-R/DSB-240AH-R
* DSA-240AH-R/DSB-240AH-R/240PH-R PART LIST (OUT DOOR UNIT)
✔ Caution: In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
