119
No PART CODE PART NAME Q'TY SPEC REMARK
1 3100300511
PAN BASE 3 SECC T1.2
092AH(DW COMP RBB100A011)
3100300531 123AH/PH(DW COMP. RCB150A001)
2 310600900 COMP. BOLT 3 MB x L46.5
092AH(DW COMP RBB100A011)
123AH/PH(DW COMP. RCB150A001)
3 3102100800 FOOT 2 SECC T1.2
4 3108134AE0 COMP. GROMMET 3 EPDM
092AH(DW COMP RBB100A011)
123AH/PH(DW COMP. RCB150A001)
5
3RC0020LE1 COMPRESSOR ASS’Y 1 RBB100A011 092AH
3RC0030HE0 RCB 150A001 123AH/PH
6
3110046300
CONDENSER ASS’Y 1 L465xW208.5xH508
092AH(DW COMP RBB100A011)
3100037010 123AH/PH(DW COMP. RCB150A001)
7 3100602200 BRACKET SERVICE 1 SECC T1.2
8 3115401900 SERVICE VALVE ASS’Y 1 3/8" (9.52)
9 3105400800 SERVICE VALVE 1 1/4"
10 3104410710 PIPE COND IN ASS’Y 1 C1220T 123AH/PH
11 3104412810 PIPE COND OUT ASS’Y 1 C1220T
092AH(DW COMP RBB100A011)
123AH/PH(DW COMP. RCB150A001)
12 3104411411 PIPE OUTLET 1 C1220T
092AH(DW COMP RBB100A011)
123AH/PH(DW COMP. RCB150A001)
13
3110048400
PIPE FILTER ASS’Y 1 C1220T
092AH(DW COMP RBB100A011)
3110083100 123AH/PH(DW COMP. RCB150A001)
14 3104400300 PIPE SENSOR 1 C1220T
15
3110048100
PIPE REVERSING ASS’Y 1 C1220T
092AH(DW COMP RBB100A011)
3100038810 123AH/PH(DW COMP. RCB150A001)
16
3105401010
REVERSING VALVE 1
CHV-0104 092AH
3105401000 VH7-ATYPE 123AH/PH
17 3102501100 GUIDE SUPPORT 1 SECC T1.2
18 3102402600 GRILLE CONDENSER 1 P.E. 660x525.5xT3.5
19 3100601903 BRACKET MOTOR 1 SBHG1 T1.2
* DSB-092AH/123AH/123PH PART LIST(OUTDOOR UNIT )
✔ Caution: In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
