No PART CODE PART NAME Q'TY SPEC REMARK
1 CONTROL PCB ASS’Y1
2 3108912300 TERMINAL BLOCK 1 SN-DBW-03P
3 3112704450 HARNESS AC SIGNAL 1 1
4 3104896300 SENSOR ID ASS’Y 1 PTM-KD43C-D2
5 3101300100 POWER CORD ASS’Y 1 16A 250V
6 3102797610 HARNESS I/D COMP 1
7 3102797910 HARNESS I/D EARTH 1
8 3102704000 HARNESS POWER 1
9 3102704500 HARNESS LED PCB 1
✔ Caution:
In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
