* DSB-182PH
Remote Control Signal Receiver
This place is the part to receive the signal if it receives
the signal, you can hear the signal Òbeep. beepÓ.
There is a switch panel at inside of Front Panel.
At the time of operating, open the Front Panel.
Emergency switch can be used when the remote
controller is lost or Testing.
Remote switch is usually used by remote controller.
Indoor Unit Display Switch Panel
ON (Red)
Light-on
during the
operation
Air clean (Green)
Light-on
during the
operation
Timer (Yellow)
Light-on during
the time of
reservation mode.
Quick (Red)
Light-on during
the time of
Quick Mode.
TIMER
QUICK
AIR CLEAN
ON
ON (Red)
Light-on
during the
operation.
Plasma (Green)
Light-on
during the
Plasma mode.
Timer (Yellow)
Light-on during
the time of
reservation mode.
Quick (Red)
Light-on during
the time of
Quick Mode.
TIMER
QUICK
PLASMA
ON
(DSB-182L/LH/L-R/LH-R) (DSB-182PH)
EMERGENCY REMOTE
