* DSB-092A/092AH/123A/123AH/123PH
Connection Cover
Remove cover to access the
AC connection
to the indoor unit.
Service Valves
The indoor and outdoor units
are connected by copper tubes
which are connected here.
AIR IN
AIR OUT
Connection Wire
O2 Hose Wire
(092A/123A/AH)
Connecting Pipe
Drain Hose
Outdoor Unit
