MAIN ELECTRIC PARTS
PART NAME PART CODE SPEC. QUANTITY REMARK
Fan Motor 3108008700 YDK-8-4B 1
Fan Motor Capacitor 3106900300 1.0uF 400VAC 1
Fuse 5FVLB3152L 250V 3.15A 1
Stepping Motor 3108003900 GSP-24SW-061 1
Terminal Block 3108912300 SN-DBW-05P 1
Compressor 3RC0020KE0 RBB095A011 1
Fan Motor 3108004100 YDK-30-6B 1
Dual Capacitor 3109501201 1.8+25µF 400VAC 1
Terminal Block 3108912300 SN-DBW-03P 1
Indoor
Unit
Outdoor
Unit
* DSB-092A
* DSB-123A
PART NAME PART CODE SPEC. QUANTITY REMARK
Fan Motor 3118003500 RP13B 1
Fan Motor Capacitor CMXW2G155K 1.5uF, 400VAC 1
Fuse 5FVLB3152L 250V 3.15A 1
Stepping Motor 3108003910 MP24GA 1
Terminal Block 3118900200 JXO-CH-2P 1
Compressor 3100030CE0 RCB120A001 1
Fan Motor 3108000800 YDK-40-4B 1
Dual Capacitor 3109500700 3.5+25µF 400VAC 1
Terminal Block 3108914200 JXO-CH-4P 1
Outdoor
Unit
Indoor
Unit
* DSB-123AH/123PH
PART NAME PART CODE SPEC. QUANTITY REMARK
Fan Motor 3118003500 RP13B 1
Fan Motor Capacitor CMXW2G155K 1.5uF 400VAC 1
Fuse 5FVLB3152L 250V 3.15A 1
Stepping Motor 3108003910 MP24GA 1
Terminal Block 3118900200 JXO-CH-2P 1
Dust Coollector 3100033200 1 DSB-123PH
Compressor 3100030CE0 RCB150A001 1
Fan Motor 3108000800 YDK-40-4B 1
Dual Capacitor 3109500700 3.5+25µF 400VAC 1
Terminal Block 3108912301 SN-DBW-05P 1
Reversing Valve 3105401000 VH7-A TYPE 1
Solenoid coil 1
Outdoor
Unit
Indoor
Unit
PART NAME PART CODE SPEC. QUANTITY REMARK
Fan Motor 3108003800 YDK-8-4B 1
Fan Motor Capacitor 3106900300 1.0uF 400VAC 1
Fuse 5FVLB3152L 250V 3.15A 1
Stepping Motor 3108003900 GSP-24SW-061 1
Terminal Block 3108912301 SN-DBW-05P 1
Compressor
3RC0020KE0 RBB100A001 1
3107101900 RBB100A011 1
Fan Motor 3108004100 YDK-30-6B 1
Dual Capacitor
3109502010 1.8+30µF 400VAC 1
3109502030 1.8+35µF 400VAC 1
Terminal Block 3108912301 SN-DBW-05P 1
Reversing Valve 3104401010 CHV-0104 1
Solenoid coil 3109700110 CHV01AJ 1
Indoor
Unit
Outdoor
Unit
* DSB-092AH
