◆DSB-240AH,PH PART LIST (INDOOR UNIT)
PART NAME SPEC QTY LOCATION
PIN GP881205-2(187) 1 CN7
PIN GP881206-2(250) 2 CC,CL
FUSE 250V 50T 3.15A 1 FUSE
WAFER SMW250-06(WHITE) 1 CN13
FUSE CLIP AFC-520 2 FUSE CLIP
WAFER YFW800-01D 1 CN8
WAFER YFW800-02D 1 CN2
WAFER YW396-05AVD(RED) 1 CN1
WAFER YW396-05AVD 1 CN3
WAFER YW396-03AVD 1 CN4
WAFER YW396-03AVD(BL) 1 CN5
WAFER SMW250-08 1 CN11
WAFER YFW254S-02 1 TEST
WAFER 5267-04A 1 CN9
WAFER 5267-02A 1 CN10
WAFER 5281-02A 1 CN6
VARISTOR 15G561K 1 VAR
DIODE 1N4004 TAPE 6 D1,2,3,4,5,6
C-CERA 103Z,50VDC 5 CC4,5,6,7,9
C-CERA 104Z,25VDC 6 CC1,2,3,8,10,11
C-MULTI 104Z,CR0561B-Z5U 1 CC13
C-ELEC 1000uF 35V SD 1 CE1
C-ELEC 470uF 25V SD 1 CE2
C-ELEC 100uF 16V SD 1 CE3
C-ELEC 10uF 16V SS 1 CE5
C-ELEC 4.7uF 50V SS 1 CE4
C-ARRAY F3 104Z 1 CA3
C-ARRAY F4 104Z 1 CA2
C-ARRAY F5 104Z 1 CA1
RESISTOR 1/4W-12.7KF 3 R9,10,11
RESISTOR 1/4W-10KJ 1 R3
RESISTOR 1/4W-5.6KJ 2 R2,13
RESISTOR 1/4W-1KJ 20 R4,12,14,15,16,17,18,19,20,21,
23,24,25,26,27,28,29,30,31,32
RESISTOR 1/4W-330J 3 R6,7,8
RESISTOR 1/4W-100J 1 R1
RESISTOR 1/2W-1KJ 1 R5
RESISTOR 1W-120J 1 R38
RESISTOR OPTION 1/4W 1% 5 * REFERE TO RESISTOR OPTION TABLE
RESISTOR ARRAY 4A 103J 1 RA3
RESISTOR ARRAY 5A 103J 1 RA2
