oors.
- Cushion pad:Used to scrub light dirt without damaging the oor.
Gravity folding pad:For powerful removal of heavy coatings or
substrates, or for extrapowerful scrubbing.
4. MACHINE INSTALLATION
Attaching the squeegee assembly
1.Park the machine on level ground and remove the key.
2.Lower the squeegee lift lever to the lower position.
3.As shown in the gure, install the squeegee onto the squeegee
mounting bracket. Be
sure to fully insert the tightening knob into the socket before
tightening the knob.
4.Connect the vacuum suction pipe to the squeegee assembly
and make a secure connection.
5.Check the squeegee blade and make appropriate adjustments.
5. INSTALL BRUSH/SCOURING PAD
Illustrate: For recommended brushes and scouring pads, please
refer to the “Brush and scouring pad information” in this manual.
Or contact your local authorized dealer.
1.Park the machine on level ground and remove the key.
2.Press the brush head lift pedal to lift the brush head off the
ground.
3.First place the scouring pad on the needle seat, then install the
drive plate, and tighten the central lock to secure the scouring
pad.
4.Align the needle holder/brush mounting pin and insert it into the
motor drive plate buckle, and press the brush plate motor switch.
