Daewoo DVQ-10H1FCN User Manual

-24-
SERVICE PARTS LIST
LY04 5CPZ560K02 COIL PEAKING 56UH K (AXIAL 3.5MM)
LZ01 5CPZ560K04 COIL PEAKING 56UH K (AXIAL 10.5MM)
R106 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R107 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R110 RD-4Z392J- R CARBON FILM 1/4 3.9K OHM J
R112 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R113 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R114 RD-AZ472J- R CARBON FILM 1/6 4.7K OHM J
R115 RD-AZ472J- R CARBON FILM 1/6 4.7K OHM J
R504 RD-4Z121J- R CARBON FILM 1/4 120 OHM J
R505 RD-AZ331J- R CARBON FILM 1/6 330 OHM J
R506 RD-AZ331J- R CARBON FILM 1/6 330 OHM J
R507 RD-AZ331J- R CARBON FILM 1/6 330 OHM J
R508 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R511 RD-AZ151J- R CARBON FILM 1/6 150 OHM J
R518 RD-AZ123J- R CARBON FILM 1/6 12K OHM J
R532 RD-4Z100J- R CARBON FILM 1/4 10 OHM J
R544 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R601 RD-AZ622J- R CARBON FILM 1/6 6.2K OHM J
R602 RD-AZ202J- R CARBON FILM 1/6 2K OHM J
R603 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
R605 RD-2Z331J- R CARBON FILM 1/2 330 OHM J
R607 RD-AZ471J- R CARBON FILM 1/6 470 OHM J
R608 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
R609 RD-AZ473J- R CARBON FILM 1/6 47K OHM J
RA01 RD-AZ104J- R CARBON FILM 1/6 100K OHM J
RA02 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
RS01 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
RS02 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
RS13 RD-4Z121J- R CARBON FILM 1/4 120 OHM J
RS17 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
RS18 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
RS19 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
RS20 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
RS21 RD-AZ274J- R CARBON FILM 1/6 270K OHM J
RS22 RD-AZ473J- R CARBON FILM 1/6 47K OHM J
RS23 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
RS24 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
RS25 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
RS26 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
RS27 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
RS28 RD-AZ223J- R CARBON FILM 1/6 22K OHM J
RS29 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
RS35 RD-AZ751J- R CARBON FILM 1/6 750 OHM J
RS38 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
RS39 RD-AZ471J- R CARBON FILM 1/6 470 OHM J
RS40 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
RS41 RD-AZ472J- R CARBON FILM 1/6 4.7K OHM J
RS42 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
RS43 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
RS44 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
RS45 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
RS50 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
RS51 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
LOC PART CODE PART NAME DESCRIPTION REMARK
RS52 RD-AZ472J- R CARBON FILM 1/6 4.7K OHM J
RS53 RD-AZ472J- R CARBON FILM 1/6 4.7K OHM J
RS54 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
RS55 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
RS56 RD-AZ472J- R CARBON FILM 1/6 4.7K OHM J
RS57 RD-AZ472J- R CARBON FILM 1/6 4.7K OHM J
RS58 RD-AZ471J- R CARBON FILM 1/6 470 OHM J
RS59 RD-AZ471J- R CARBON FILM 1/6 470 OHM J
RS62 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
RS63 RD-AZ473J- R CARBON FILM 1/6 47K OHM J
RS69 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
RS70 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
RS75 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
RS76 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
RS77 RD-AZ472J- R CARBON FILM 1/6 4.7K OHM J
RS78 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
RS79 RD-AZ332J- R CARBON FILM 1/6 3.3K OHM J
RS88 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
RS90 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
RS91 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
RS92 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
RT01 RD-AZ240J- R CARBON FILM 1/6 24 OHM J
RT02 RD-AZ472J- R CARBON FILM 1/6 4.7K OHM J
RT03 RD-AZ331J- R CARBON FILM 1/6 330 OHM J
RT04 RD-AZ331J- R CARBON FILM 1/6 330 OHM J
RT05 RD-AZ472J- R CARBON FILM 1/6 4.7K OHM J
RT06 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
RT07 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
RT08 RD-AZ331J- R CARBON FILM 1/6 330 OHM J
RT10 RD-AZ681J- R CARBON FILM 1/6 680 OHM J
RT16 RD-AZ681J- R CARBON FILM 1/6 680 OHM J
RU02 RD-AZ563J- R CARBON FILM 1/6 56K OHM J
RU04 RD-AZ753J- R CARBON FILM 1/6 75K OHM J
RU07 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
RU21 RD-AZ223J- R CARBON FILM 1/6 22K OHM J
RU22 RD-AZ470J- R CARBON FILM 1/6 47 OHM J
RU26 RD-AZ223J- R CARBON FILM 1/6 22K OHM J
RU30 RD-AZ561J- R CARBON FILM 1/6 560 OHM J
RV01 RD-AZ750J- R CARBON FILM 1/6 75 OHM J
RV02 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
RY01 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
RY04 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
RY05 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
RY06 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
RY07 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
RY08 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
RY13 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
RY23 RD-AZ222J- R CARBON FILM 1/6 2.2K OHM J
RY26 RD-AZ102J- R CARBON FILM 1/6 1K OHM J
RY28 RD-AZ182J- R CARBON FILM 1/6 1.8K OHM J
RY36 RD-AZ101J- R CARBON FILM 1/6 100 OHM J
RY39 RD-AZ103J- R CARBON FILM 1/6 10K OHM J
RY42 RD-AZ184J- R CARBON FILM 1/6 180K OHM J
ZZ300 PTPWMSH611 PCB POWER MANUAL AS DVQ-10H1FCN
