-25-
SERVICE PARTS LIST
C402 CMYE2D274J C MYLAR 200V PU 0.27MF J
C416 CMYH3C692J C MYLAR 1.6KV BUP 6900PF J
C451 CMYL2E475J C MYLAR 250V MEU 4.7MF J
C801 CL1UC3474M C LINE ACROSS 0.47MF 1J(UCVSNDF/SV)+Q/O
C804 CEYN2D331P C ELECTRO 200V LHS 330MF
C805 CMYH3A472J C MYLAR 1KV BUP 4700PF J
D822 DRGP30J--- DIODE RGP30J
D855 DRGP30J--- DIODE RGP30J
F801 5F1GB4021L FUSE GLASS TUBE UL/CSA TL 4A 125V MF51
I301 PTD2SW7100 HEAT SINK ASS`Y 1LA78041-- + 7174300811
00001 1LA78041-- IC VERTICAL LA78041
0000A 4857027100 HEAT SINK SPCC T1.0+SN
0000B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN
I451 TTF341M--- THYRISTOR TF341M
I801 1LTV817C-- IC PHOTO COUPLER LTV-817C
I802 1LTV817C-- IC PHOTO COUPLER LTV-817C
I807 1KA7500C-- IC KA7500C
JP801 4859101110 JACK DC YSC-1535
L801 5PLF24A1-- FILTER LINE LF-24A1
L850 58C0000132 COIL CHOKE CH-100W
M381 4851949100 FRAME MAIN PCB AS 3818800+7249500
M381A 7178301011 SCREW TAPPTITE TT2 WAS 3X10 MFZN
M681 4853535500 HOLDER CORD NYLON 66
P901 4859284620 CONN WAFER SMW250-05
P902 4859284520 CONN WAFER SMW250-04
PA902 4850704N26 CONNECTOR SMH250-04+YBNH250+ULW=200
PWC1 4859907910 CORD POWER AS ME301P+TER=1830
Q402 PTA2SW7201 HEAT SINK ASS`Y T2SD2627YB + 7174300811
00001 T2SD2627YB TR 2SD2627LS-YB
0000A 4857027201 HEAT SINK AL T1.0
0000B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN
Q801 PTQ2SW4510 HEAT SINK ASS`Y T2SK2564-- + 7174300811
00001 T2SK2564-- FET 2SK2564
0000A 4857024510 HEAT SINK AL EX
0000B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN
0000C 4856815900 CLAMP WIRE EGI T0.4+PVC COATING
0000D 7174301011 SCREW TAPPTITE TT2 RND 3X10 MFZN
Q851 PTD2SW7603 HEAT SINK ASS`Y TFQPF85N06 + 7174300811
00001 TFQPF85N06 FET FQPF85N06
0000A 4857027603 HEAT SINK AL EX
0000B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN
R801 DSVC471D14 VARISTOR SVC471D14A
R802 RX07B229JQ R CEMENT 7W 2.2 0HM J BEN 25MM 4P
SCT01 4859303930 SOCKET CRT ISMG03S INCHANG
T401 50D10A3--- TRANS DRIVE TD-10A3
T402 50H0000246 FBT TCG-30U63
T801 50M3541B5- TRANS SMPS TSM-3541B5
T802 50M3541B2- TRANS SMPS TSM-3541B2
ZZ200 PTPWJ0H611 PCB POWER ODD SHAPE (RHU) ASDVQ-10H1FCN
C308 CEXF1E102V C ELECTRO 25V RSS 1000MF (13X20) TP
C401 CEXF2C470V C ELECTRO 160V RSS 47MF (13X25) TP
C404 CEXF2E100V C ELECTRO 250V RSS 10MF (10X20) TP
C407 CEXF1C102V C ELECTRO 16V RSS 1000MF (10X20) TP
C410 CEXF1V471V C ELECTRO 35V RSS 470MF (10X20) TP
LOC PART CODE PART NAME DESCRIPTION REMARK
C453 CEXF2E479V C ELECTRO 250V RSS 4.7MF (10X16)TP
C821 CEXF2C101V C ELECTRO 160V RSS 100MF (16X25) TP
C823 CEXF1C102V C ELECTRO 16V RSS 1000MF (10X20) TP
C824 CEXF1E471V C ELECTRO 25V RSS 470MF (10X16) TP
C829 CEXF1C102V C ELECTRO 16V RSS 1000MF (10X20) TP
C851 CEXF1E222C C ELECTRO 25V RUS 2200MF (16X25) TP
C888 CH1BEE472M C CERA AC U/C/V 2.5KV 4700PF TP
C889 CH1BEE472M C CERA AC U/C/V 2.5KV 4700PF TP
C965 CH1BEE472M C CERA AC U/C/V 2.5KV 4700PF TP
L804 58Q0000093 COIL DELAY LINE RS208
ZZ200 PTPWJBH611 PCB POWER M-10 AS DVQ-10H1FCN
E001 4856310300 EYE LET BSR T0.2 (R1.6)
E002 4856310300 EYE LET BSR T0.2 (R1.6)
E003 4856310300 EYE LET BSR T0.2 (R1.6)
E004 4856310300 EYE LET BSR T0.2 (R1.6)
E005 4856310600 EYE LET BSR T0.2 (R2.3)
E006 4856310600 EYE LET BSR T0.2 (R2.3)
E007 4856310300 EYE LET BSR T0.2 (R1.6)
E009 4856310300 EYE LET BSR T0.2 (R1.6)
E010 4856310300 EYE LET BSR T0.2 (R1.6)
E011 4856310300 EYE LET BSR T0.2 (R1.6)
E012 4856310300 EYE LET BSR T0.2 (R1.6)
E013 4856310300 EYE LET BSR T0.2 (R1.6)
E014 4856310300 EYE LET BSR T0.2 (R1.6)
E015 4856310300 EYE LET BSR T0.2 (R1.6)
E016 4856310300 EYE LET BSR T0.2 (R1.6)
E017 4856310300 EYE LET BSR T0.2 (R1.6)
E018 4856310300 EYE LET BSR T0.2 (R1.6)
E019 4856310300 EYE LET BSR T0.2 (R1.6)
E020 4856310300 EYE LET BSR T0.2 (R1.6)
E021 4856310300 EYE LET BSR T0.2 (R1.6)
E022 4856310600 EYE LET BSR T0.2 (R2.3)
E023 4856310600 EYE LET BSR T0.2 (R2.3)
E024 4856310600 EYE LET BSR T0.2 (R2.3)
E025 4856310600 EYE LET BSR T0.2 (R2.3)
E026 4856310300 EYE LET BSR T0.2 (R1.6)
E027 4856310300 EYE LET BSR T0.2 (R1.6)
E028 4856310300 EYE LET BSR T0.2 (R1.6)
E029 4856310300 EYE LET BSR T0.2 (R1.6)
E030 4856310300 EYE LET BSR T0.2 (R1.6)
E031 4856310300 EYE LET BSR T0.2 (R1.6)
E032 4856310300 EYE LET BSR T0.2 (R1.6)
E033 4856310300 EYE LET BSR T0.2 (R1.6)
E034 4856310300 EYE LET BSR T0.2 (R1.6)
E035 4856310600 EYE LET BSR T0.2 (R2.3)
E036 4856310600 EYE LET BSR T0.2 (R2.3)
E037 4856310600 EYE LET BSR T0.2 (R2.3)
E038 4856310600 EYE LET BSR T0.2 (R2.3)
E039 4856310600 EYE LET BSR T0.2 (R2.3)
E040 4856310600 EYE LET BSR T0.2 (R2.3)
E041 4856310600 EYE LET BSR T0.2 (R2.3)
E042 4856310600 EYE LET BSR T0.2 (R2.3)
E043 4856310600 EYE LET BSR T0.2 (R2.3)
N001 4857417500 TERM PIN DA-IB0214(D2.3/DY PIN)
LOC PART CODE PART NAME DESCRIPTION REMARK
