10
Chapter 2 : Connecting an Antenna or Cable to Your TV/VCR
Antennas with two sets of leads
You might have two sets of leads from your antenna system, especially if you have one anten-
na for VHF signals and one antenna for UHF signals.
If your antenna system has both a coaxial lead and twin 300-ohm leads
, you must obtain a com-
biner (available at your local electronics store). Press or screw the coaxial lead onto the com-
biner; place the twin leads underneath the screws on the combiner and tighten the screws.
Press the cable from combiner onto the antenna terminal on the back of the TV/VCR.
If your antenna system has two sets of twin 300-ohm leads, you must obtain a combiner
(available at your local electronics store). Place one set of twin leads underneath the screws on
the combiner and tighten the screws. Do the same with the other set of twin leads. Press the
cable from the combiner onto the antenna terminal on the back of your TV/VCR.
