Daewoo DW-1010 - Parts List: Cabinet Assembly; Parts List: Base U Assembly

Página 16 de 19
3. ENSAMBLE GABINETE
Código de Parte Especificación
Loc. Nombre de la Parte
DWW-1360 DW -1010/11 DWW-1360 DW -1010/11
Cant.
C01 CABINET 3610808533 3610809900 C/SKD(PCM0.6) PCM SGCC 1
C02 CAP HANDLE 3612603300 PP 2
C03 UNIT CAPACITOR 36189L4C00 3618970000
54uF,200VAC,L=470 36UF 250V 50/60HZ,470MM
1
C04 SCREW TAPPING 7122401211 T2S TRS 4X12 MFZN 4
C05 PLATE UPPER 3614514600 3614519400 PP 1
C06 COVER B 3611413605 3611414010 0.35T 372*508*0.4T, SGCC 1
C07 SCREW TAPPING 7112401011 T1 TRS 4X10 MFZN 4
4. ENSAMBLE BASE U
Código de Parte Especificación
Loc. Nombre de la Parte
DWW-1360 DW -1010/11 DWW-1360 DW -1010/11
Cant.
D01 SPECIAL BOLT AS 3616000703 N/A
6B-1-6*20(NON SILOCK)
1
D02 PULLEY MOTOR 3618433300 3618431600 ALDC,A-TYPE,DP 40
SGCC1.2T,D24 ,4.3MM
1
D03 SPECIL BOLT 3616003100 M5X35 WASHER 4
D04 UNIT MOTOR AS 3618971610 3618966100 W1N50NA002,127/60,L570
W1D50ND001, 120V 60HZ
1
D05 CUSHION MOTOR 3611564800 N/A POM, MEXICO,13Kg 2
D06 BELT V 3616590800 A-25 1
D07 POWER CORD WAK42H762- A VCTFK 2X0.75 2.3M GY 1
D08 SUPPORTER TUB 3615303900 3618966100
PVC PIPE, DO=38,L=158.5 W1D50ND001, 120V 60HZ
3
D09 BASE U 3610392400 3610391000 PP 1
D10 SCREW TAPPING 7112401211 T1 TRS 4X12 MFZN 11
D11 ROLLER 4505A10010 JPA6 4
D12 SHAFT ROLLER 4509A10020 JSWRM4 MFZN 4
D13 WASHER SPRING NA 7401008011 SW-8MFZN 1
D14 NUT HEX NA 7392800011 M8XP1.25 MFZN 1
D15 WASHER PLAN NA 7400108411 1
D16 MOTOR CUSHION NA 450M712020 NR 3
D17 CUSHION SPOT NA 450M712010 PP 1
