Daewoo DW-1010 - Parts List: Top Plate and Tub Assemblies

Página 15 de 19
7. Lista de partes
1. ENSAMBLE TOP PLATE
Código de Parte Especificación
Loc. Nombre de la Parte
DWW-1360 DW -1010/11 DWW-1360 DW-1010/11
Cant.
A01 KNOB 3613404900 3613404100 ABS 2
A02 PANEL B 3614283400 3614275700 HIPS, 260WA HIPS 1
A03 SCREW TAPPING 7122401411 T2S 4X14 MFZN 2
A04 BRACKET CONTROL 3610608200 3610606800 PP 1
A05 SWITCH SELECTOR 3619045700 3619044600 GSM-V1623A4 SZM-V15-2FA-93 2 / 1
A06 LEVER CONTROL 3613701400 DWM-800C,POM 1
A07 TIMER WASH 3619911410 3619911400 30MIN, DJT-30-1 30 MIN, 125V/6A, S-W20NT 1
A08 PCB AS PRPSSWY700 DWW-200WA(MEXICO) 1
A09 SCREW TAPPING 7122401411 T2S 4X14 MFZN 5
A10 HARNESS AS 3612794800 3612791700 260WA, UL VSF 20/0.18 1
A11 PLATE T 3614532500 3614526800 HIPS, 260WA HIPS 1
A12 BUSHING HINGE 3610702100 PP 2
A13 CAP CUSHION 3610913000 NR 2
A14 SCREW TAPPING 7122401411 T2S 4X14 MFZN 2
A15 PLATE PROTECTOR 3614527700 SUS T1.0 2
A16 SCREW TAPPING 7122300808 T2 TRS 3X8 SUS 2
A17 SCREW TAPPING 7122401411 N/A T2S 4X14 MFZN 1
A18 SPECIAL SCREW 3616009900 FLT 3.5X7 SUS430 4
A19 DOOR HINGE L 3612902600 SUS 1
A20 DOOR HINGE R 3612902500 SUS 1
A21 DOOR 3611421500 SGCC 1
2. ENSAMBLE TINA
Código de Parte Especificación
Loc. Nombre de la Parte
DWW-1360 DW -1010/11 DWW-1360 DW-1010/11
Cant.
B01 CAP AGITATOR 3610912901 3610912900 PP 1
B02 SPECIAL SCREW 3616002801 SUS 430 (NON SILOCK) 1
B03 PULSATOR AGITATOR AS
3619707101 3619707100 PP + INSERT 1
B04 COVER IMPELLER 3611426200 N/A ABS 4
B05 FAN IMPELLER 3611885800 N/A PP 4
B06 SCREW TAPPING 7122400814 N/A T2S TRS 4X14 SUS 4
B07 DRAIN STRAINER 3619615000 PP 1
B08 TUB 3618821200 3618819100 PP 1
B09 SCREW TAPPING 7112401211 T1 TRS 4X12 MFZN 11
B10 DRAIN HOSE ASSY 3613222910 36196005C1 1100mm,NON CLAMP
L=1050 1
B11 RING O 4504B02050 NR 1
B12 BOX GEAR ASSY 3617306110 DWW-200WA, D14 1
B13 SPECIAL SCREW 4504B02090 T2 6.1X25 MFZN 6
B14 PULLEY PULSATOR 3618433000 FRPP 1
B15 SPECIAL BOLT 3616008400 M6 SIDE-FIXING 1
