Specification
Wiring diagram
MODEL DWC-ED1432
Dimension WxDxH (mm) 598 X 625 X 850
Maximum Mass Of Textile (kg) 10kg / 7kg
Unit Weight (Net / Gross) 67kg / 70.5kg
Spin Speed (RPM) Max 1400
Operating Water Pressure 0,03MPa ~ 0,80MPa (0,30kgf/cm
2
~ 8,00kgf/cm
2
)
Rated Voltage 230V
Rated Frequency 50Hz
Rated Power 2000W
Dry Rated Power 1800W
IP Code IPX 4
