4. HEATER
1) SPEC. OF HEATER
Part Name
Maker
Power source
Power Consumption
Resistance
Current Density
Temperature fuse
Thermistator
Material
Part Code
heater wash
IRCA
110V
1000W
±5%
12.1
4.3
144℃
Combined in heater
SUS430
361280110
heater dry
IRCA
110V
1200W±5%
10.08
3.5
128℃(exterior)
exterior
INCLOY800
3612801300
1. Temperature fuse
•If the heater is on without water, because of pressure switch trouble, fire can be occurred.
Temperature fuse prevents this hazard of fire.
•The heater wash must be submerged in water.
2. The device for overheating prevention of the dry heater
•Temperature fuse : 128℃cut-off type, 250V 15A
•Thermostat : 150℃off 120℃on,230V 15A
