Daewoo DWD-F1021 - SPECIFICATION; Technical Specifications; WIRING DIAGRAM; Wiring Diagram

23
Dimension (mm)
Maximum mass of textile (kg)
Unit Weight (kg)
Standard Water Consumption
Spin Speed (RPM)
Operating Water Pressure
595 x 540 x 850 (WxHxD)
6.0
64(Net) / 68(Gross)
50 l
No Spin/400/800/1000 No Spin/400/800/1200
0.03MPa ~ 0.8MPa (0.3kgf/cm
2
~ 8kgf/cm
2
)
MODEL DWD-F1021/F1022/F1023 DWD-F1221/F1222/F1223
SPECIFICATION
WIRING DIAGRAM
