21
EXPLODE VIEW AND PARTS LIST
E01 CABINET 3610811101 SGCC(GI), 0.7TX825.7X1630.8 1
E02 FRAME LOWER 3612205501 SGCC T1.0 160X580 1
E03 FRAME TOP *L 36122UDY00 SGCC T=1.2, FT1081 1
E04 FRAME TOP *R 36122UDZ00 SGCC T=1.2, FT1081 1
E05 BASE UNDER *L 3610392201 SGCC T1.4 100x500 1
E06 BASE UNDER *R 3610392301 SGCC T1.4 100x500 1
E07 FRAME UPPER 36122UE000 SGCC 1.0T, FT1081 1
E08 SCREW TAPPING 3616029950 TTS"S" HEX F/L 4X8 4
E09 SPECIAL BOLT 3616029100 M4x12.5, MACHINE 2
E10 STOPPER SPRING 3615202200 POM 2
E11 COVER BACK AS 3611425520 COVER BACK+CUSHION 1
E12 SENSOR PRESSURE 3614825330 DL-DW11-H AIR INLET 90 HOOK TYPE 1
E13 UNIT DRAIN PUMP AS 36189L5K20 AL.220-240/50 B20-6 30W 6KG 1
220-240V 50Hz
36189L5J20 AL.220/60 B20-5 35W 6KG 1 220V 60Hz
E14 CAP WATER REMAIN 3610916800 PP 1
E15 HOSE WATER REMAIN 3613268700 EPDM, ID8.5, L200 1
E16 LEG ADJUST AS 3617703811 CHINA PARTS, DWD-900W 4
E17 HOSE DRAIN OUTER AS 3613274920 D-F'S L1960, EXPORT GENERAL 1
E18 CLAMP HOSE 3611204701 DI=26 1
E19 CLAMP HOSE 3611206410 NYLON, DA-16N, ID21.9 D-MU80 1
E20 SCREW TAPPING 7122401411 T2S TRS 4*14 MFZN 1
No. PART NAME PART CODE SPECIFICATION Q'TY REMARK
1 piece
SVC part
