Daewoo Forkilt - Drive Wheel Bearing (Power Shaft and Drive Wheel) - Reassemble

Maintenance Section
-191-
Drive Wheel Bearing (Power Shaft
and Drive Wheel) – Reassemble
Consult your DAEWOO lift truck dealer for the
proper wheel bearing reassembling procedure.
Packing of bearings and adjustment procedure
must be made by a trained mechanic or dealer
personnel.
Pack power shaft bearings (1) and spindle bearings
(2). Pack ring gear (3) to the depth of the teeth.
D, G-Series Lift Trucks
Torque for single or dual wheel mounting nuts (1) is
644 ± 34 N•m (470 ± 25 lb•ft).
Torque for adapter assembly bolts (2) is 285 ± 13
N•m (210 ± 10 lb•ft).
Tighten wheel bearing nut (3) to 135 N•m (100 lb•ft)
while the wheel is turned in both directions. Loosen
the nut completely and tighten nut again to 50 ± 5
N•m (37 ± 4 lb•ft). Bend the lock washer tab into a
groove of the nut.
Torque for bolts (4) that hold cover to drive axle
housing is 55 ± 10 N•m (40 ± 7 lb•ft).
Apply Loctite No.242 to threads of spindle bolts
(5).Torque for spindle bolts is 115 ± 14 N•m (85 ±
10 lb•ft).
GC-Series Lift Trucks.
Torque for wheel bolts (1) is 270 ± 25 N•m (200 ±
20 lb•ft).
Tighten wheel bearing nut (2) 135 N•m (100 lb•ft)
while the wheel is turned in both directions. Loosen
the nut completely and tighten nut again to 50 ±5
N•m (37 ± 4 lb•ft). Bend the lock washer tab into a
groove of the nut.
Torque for bolts (3) that hold cover to drive axle
housing is 55 ± 10 N•m (40 ± 7 lb•ft).
Apply Loctite No. 242 to threads of spindle bolts (4).
Torque for spindle bolts is 115 ± 14 N•m (85 ± 10
lb•ft).
