Point Oscilloscope Measurement Remark
I
* Control mode of non
constant voltage
* Point F is wave form
under 10V.
* It controls constant
voltage mode by
sensing pulse width
according to the
amount of voltage.
e) Control Circuit of Constant Voltage
