76
10-2. If the refrigerator can not enter the door
Removing Freezer Door
1
※Remove front bottom cover first, if it is attached.
Remove front bottom cover first,
Pull out the left collar of the
coupling first, then hold the
coupling and pull out the left
water tube. (Dispenser Models)
2
Unscrew top hinge cover with a
screw driver.
Remove the hinge cover.
3
Turn top hinge bolt
counterclockwise .
Disconnect the harness wires.
4
Lift up the front of hinge to remove.
( After the hinge is removed the
door can fall down forward.
Be careful !)
5
Be careful not to damage the
water line when removing the
door.
Removing Refrigerator Door
1
Unscrew top hinge cover with a
screw driver.
Remove the hinge cover.
2
Turn top hinge fastener
counterclockwise.
Disconnect harness wires.
3
Lift up the front of hinge to remove.
(After the hinge is removed the
door can fall down forward.
Be careful !)
4
Lift the door straight up to remove.
To Next Page
