Daewoo FRS-U20IV - HOW TO CHECK EACH PART (Dispenser Components); Dispenser Solenoid Valve Check

3. Dispenser Micro Switch (Dispenser Models Only)
1) Disassembling Procedure (Features are model dependent)
2) How to check the Hose Ice Maker Tube As.
HOW TO CHECK EACH PART
No No
Dispenser Button and pull up.
1
Pull out the Micro Switch.
( Be careful not to damage the hook. )
Procedure Procedure
2
Insert (-) screw driver into bottom hole of
; Check both terminals (Red circle) with a Multi-Tester.
(Test Mode : Resistance )
; (If defective) Exchage new one.
OFF (Open)
Disconnected No Value
Tact Switch (Blue circle)
Some Value
Test ResultTermainals (Red circle)
ON (Close)
Connected
32
