G420E/G424E Tier LP Engine N2001 Regulator/Converter 63
SENSOR POINT TO POINT EXPECTED RANGE
VR SENSOR
VR PIN 1 (+) TO PIN 2 (-) ~320Ω
COIL PIN A (SIGNAL) TO PIN B ~10KΩ
COIL PIN A (SIGNAL) TO PIN D ~34KΩ
COIL PIN A (SIGNAL) TO PIN E
(PWR)
~15KΩ
COIL PIN B TO PIN D ~44KΩ
COIL PIN B TO PIN E (PWR) ~26KΩ
SMART COIL
COIL PIN D TO PIN E (PWR) ~17KΩ
CONNECTOR POINT TO POINT EXPECTED RANGE
FTV
(FUEL TRIM VALVE)
FTV PIN A (SIGNAL) TO PIN B
(PWR)
(~26Ω +/-2Ω)
CONNECTOR POINT TO POINT EXPECTED RANGE
FUEL LOCK-OFF
LOCK-OFF PIN A (PWR) TO PIN B
(GND SIGNAL)
~20-25Ω
Voltage Checks
SENSOR POINT TO POINT EXPECTED RANGE
APP1: PIN B (SIGNAL A) TO PIN C
(GND)
0.4 +/- 0.1V AT LOW IDLE
3.6 +/- 0.15V AT FULL ACCEL
ACCELERATION PEDAL ANGLE
SENSOR
APP2: PIN E (SIGNAL B) TO PIN
D (GND)
4.5 +/- 0.1V AT LOW IDLE
1.4 +/- 0.15V AT FULL ACCEL
Note: When you check the output voltage of acceleration pedal angle sensor, it must be connected to SECM so
that SECM can supply 5V to the angle sensor.
