Maintenance Section
-196-
Replace Gasoline Secondary Fuel
Filter(G424E/G430E Dual Fuel
Only)
Park the lift truck in an authorized refueling area
with the forks lowered, parking brake applied and
the transmission in Neutral.
1. Place the fuel select switch in the Gasoline
position. Remove the fuse for the electric fuel
pump.
2. Start and run the engine until the fuel in the
system runs out of fuel and the engine stops.
Turn off the ignition switch.
3. Replace the fuel filter taking care to install the
new filter with flow in the proper direction.
4. Re-install the fuse for the pump and crank the
engine several times before attempting a start
to prime the fuel pump.
G424E Dual Fuel
.(1) Primary fuel filter. (2) Fuel pump. (3) Secondary fuel filter.
G430E Dual Fuel
(1) Primary fuel filter. (2) Fuel pump. (3) Secondary fuel filter.
WARNING
When assembling the filters, check the arrow
mark on the filter surface.
The arrow mark position is same as fuel flow
direction.
1
2
3
1
2
3
