General Section
-36-
Specifications
CHARACTERISTICS
1 Manufacturer DHI&M DHI&M
2 Model GC20E-3 GC25E-3
3 Capacity at rated load center kg 2000 2500
4 Load center distance mm 500 500
5 Power type electric, diesel, gasoline, LPG gasoline / LPG gasoline / LPG
6 Operator type stand-on, rider seated rider - seated rider - seated
7 Tires* c = cushion, p = pneumatic c c
8 Wheels (x = driven) number, front/rear X 2/2 X 2/2
DIMENSIONS
9 maximum fork height with rated load mm 3230 3230
10 free lift mm 152 152
11
Lift with STD
two - stage mast
special free lift mm
12 Fork carriage ISO class ll ll
thickness X width X length mm 45 X 100 X 1050 45 X 100 X 1050
13 Forks
fork spacing (minimum X maximum) mm 297 X 905 297 X 905
14 Tilt of mast forward/backward deg 6/8 6/8
15 length without forks mm 2218 2268
16 width mm 1110 1110
17 mast lowered height mm 2125 2125
18 mast extended height mm 4470 4470
19 overhead guard height mm 2150 2150
20
Overall
dimensions
seat height mm 1038 1038
21 Outside turning radius mm 2000 2045
22 Load moment constant (from center of front wheel to fork face) mm 374 374
23 90° stacking aisle (add load length and clearance) mm 2374 2419
23a 90° intersecting aisle mm 1798 1822
PERFORMANCE
24 travel, loaded/unloaded km/h 17.5/17.9 17.4/17.8
25 lift, loaded/unloaded mm/s 530/600 510/600
26
Speeds
lowering, loaded/unloaded mm/s 510/460 510/460
28 Drawbar pull at 1.6 km/h, loaded/unloaded kg 1630/ 1590/
30 Gradeability at 1.6 km/h, loaded/unloaded % 31.2/ 26.2/
31 Acceleration time traveling loaded/unloaded s
WEIGHT
32 Total weight at unloaded kg 3380 3680
33
with load front/rear kg 4730/650 5470/710
34
Axle load
without load front/rear
kg 1490/1890 1420/2260
CHASSIS
35 number of front/rear 2/2 2/2
36 front size 21 X 7 - 15 21 X 7 - 15
37
Tires
rear size 16 X 5 - 10.5 16 X 5 - 10.5
38 Wheelbase mm 1410 1410
39 Tread front/rear mm 932/983 932/983
40 at the lowest point mm 90 90
41
Ground clearance
at the center of wheelbase mm 135 135
42 Service brake foot/hydraulic foot/hydraulic
43 Parking brake hand/mechanical hand/mechanical
DRIVE
45 Battery voltage/capacity V/AH 12/45 12/45
49 manufacturer/model DHI&M/G424 DHI&M/G424
50 rated output (at rpm) gas/LPG kW 34.5(2300) 34.5(2300)
51 max. torque (at rpm) gas/LPG kg - m 16.3(1600) 16.3(1600)
52 cycle/cylinders/displacement cc 4/4/2350 4/4/2350
53
Engine
fuel consumption l/hr
55 type Powershift Powershift
56
Transmission
number of speeds forward/reverse 1/1 1/1
* Solid soft rider tires are available instead of pneumatic as an option.
