NO. NAME SYMBOL SPECIFICATION PART CODE Q’TY
1 BUZZER BZ1 BM-20K 3515600100 1
2 C ARRAY CA1 7P(6) 1000PF M 50V CN6XB-102M 1
3 CAPACITOR ELEC EC1 50V RS 1MF CEXE1H109A 1
4 CAPACITOR ELEC EC2 25V RSS 1000MF CEXF1E102V 1
5 CONNECTOR WAFER CN1 YW396-02V 3519150520 1
6 CONNECTOR FILM CN2 FCZ 254-11 441M367160 1
7 CONNECTOR WAFER CN3 YW396-05AV 3519150510 1
8 DIODE RECTIFY D1~6,9~12,15 1N4148 DZN4148--- 11
9 DIODE RECTIFY D13,14 KN4004A DZN4004A-- 2
10 DIODE ZENER ZD1 UZ- 5.1BSB 1/2W DZUZ5R1BSB 1
11 DIODE ZENER ZD2 UZ- 3.9BSB 1/2W DZUZ3R9BSB 1
12 LED DISPLAY DP1 DDG-631H01 DDDG631H01 1
13 PCB MAIN M158 81.5X139.9 3514315410 1
14 R ARRAY RA1 7P(6) 1/8 100K J RA-87X104J 1
15 RESISTOR R1~7 1/6W 220 5% RD-AZ331J- 7
16 RESISTOR R8,10,12,14,22 1/6W 1K 5% RD-AZ102J- 5
17 RESISTOR R11,20,21 1/6W 100K 5% RD-AZ104J- 3
18 RESISTOR R13 1/6W 200 5% RD-AZ201J- 1
19 RESISTOR R15,16 1/6W 10K 5% RD-AZ103J- 2
20 RESISTOR R17 1/6W 510 5% RD-AZ511J- 1
21 RESISTOR R18 1/6W 1M 5% RD-AZ105J- 1
22 RESISTOR R23 1/6W 4.7K 5% RD-AZ472J- 1
23 RESISTOR R19 1/4W 51 5% RD-4Z510J- 1
24 RESONATOR CERA CR1 CRT 4.00MS 5P4R00MTS- 1
25 IC REGULATOR VL1 MC7905C 1MC7905C-- 1
26 TRANSISTOR Q1~5,9~11 KRA-106M TZRA106M-- 8
27 TRANSISTOR Q6 KTA-1266Y TZTA1266Y- 1
28 CAPACITOR CERA C6 102 50V Z AXIAL CCZB1H102K 1
29 CAPACITOR CERA C1,C2~5,C7 104 50V Z AXIAL CCZF1H104Z 6
30 TRANS POWER LVT1 DMR-631FS 5EPU035302 1
31 WIRE COPPER J1~3,5,21 1/0.52 TIN COATING 85801052GY 5
32 WIRE COPPER J11,12,18~20 1/0.53 TIN COATING 85801053GY 5
33 WIRE COPPER J6~8,10,17 1/0.54 TIN COATING 85801054GY 5
34 WIRE COPPER SJ4 1/0.52 TIN COATING 85801052GY 1
35 SW RELAY RY2 CS11-12SH 1C 1P 5SC0101128 1
36 IC MICOM IC1 TMP47C440BN-3J52 13GS1B4H00 1
37 SW RELAY RY1 G5G-1A DC12V 5SC0101121 1
3. P.C.B. LOCATION NO.
1) KOR-6C0B5S
