Daewoo KOR664BWTAE013AB00 - Pcb Location no

28
3. PCB LOCATION NO.
NO NAME SYMBOL SPECIFICATION PART CODE Q'TY
1 BUZZER BZ1 BM-20K 3515600100 1
2 CAPACITOR CERAMIC C1,2,3,8,9 50V 0.1UF Z AXIAL CCZF1H104Z 5
3 CAPACITOR CERAMIC C4,5,6,7 50V 1000PF Z AXIAL CCZB1H102K 4
4 CAPACITOR ELECTRO EC1 50V RS 10UF(5X11) CEXE1H100A 1
5 CAPACITOR ELECTRO EC2 50V RSS 220UF(10X16) CEXF1H221V 1
6 CAPACITOR ELECTRO EC3 25V RSS 1000UF(13X20) CEXF1E102V 1
7 CONNECTOR WAFER CN1 FCZ254-8 441M367130 1
8 CONNECTOR WAFER CN2 YW396-725V 3519150550 1
9 DIODE SWITCHING D1~10 1N4148 DZN4148--- 10
10
DIODE RECTIFYING
D11~13
1N4004A AUTO 52MM
DZN4004A--
3
11 DIODE ZENER ZD1 UZ -5.1BSB DZUZ5R1BSB 1
12 DIODE ZENER ZD2 UZ -3.3BSB DZUZ3R3BSB 1
13 DIODE ZENER ZD3 UZ -5.6BSB DZUZ5R6BSB 1
14 FOAM - CR 8TX35X10 3517307000 1
15 LED DISPLAY DP1 E40393-I JOW DHLBW439G- 1
16 IC MICOM IC1 HMS87C1408B(OTP) 150LC1408B 1
17 PCB MAIN M325-2 65X139 40303-0004301-00 1
18 RESISTOR R13 1/6W 200 OHM 5% RD-AZ201J- 1
19 RESISTOR R1~6,8~10 1/6W 560 OHM 5% RD-AZ561J- 9
20 RESISTOR R15,27,28 1/6W 1K OHM 5% RD-AZ102J- 3
21 RESISTOR R21,26 1/6W 4.7K OHM 5% RD-AZ472J- 2
22 RESISTOR R12,17,19,23 1/6W 10K OHM 5% RD-AZ103J- 4
23 RESISTOR R24 1/6W 47K OHM 5% RD-AZ473J- 1
24 RESISTOR R11,16,20,22 1/6W 100K OHM 5% RD-AZ104J- 4
25 RESISTOR R7 1/6W 1M OHM 5% RD-AZ105J- 1
26 RESISTOR R25 1/4W 51 OHM 5% RD-4Z510J- 1
27 RESISTOR R31 1/4W 100 OHM 5% RD-4Z101J- 1
28 RESISTOR R29,30 1/2W 27 OHM 5% RD-2Z270JS 2
29 RESONATOR CERAMIC CR1 CRT-4.00MS 5P4R00MTS- 1
30 SW RELAY RY1 GS5-1A-12DT 5SC0101123 1
31 SW RELAY RY2 HF32F 012-HSL3 5SC0101128 1
32 TRANSISTOR Q5,7 KTA1266Y AUTO TZTA1266Y- 2
33 TRANSISTOR Q6,8 KTC3198GR AUTO TZTC3198GR 2
34 TRANSISTOR Q1~4 KRA106M AUTO TZRA106M-- 4
35 TRANSISTOR Q9,10 KRC106M AUTO TZRC106M-- 2
36 TRANS POWER LVT1 DMR-63KP US 40512-0016500 1
37 WIRE COPPER 7.5MM J1,2,4,5,7,8 1/0.52 TIN COATING 85801052GY 6
38 WIRE COPPER 10MM J3,6, 1/0.52 TIN COATING 85801052GY 2
39 RESISTOR R14 1/6W 20K OHM J RD-AZ203J- 1
40 RESISTOR R18 1/6W 4.7K OHM J RD-AZ472J- 1
