EXPLODED VIEW AND PARTS LIST
5. HOSE ASSEMBLY
No PART NAME CODE SPEC Q’TY
1 ADAPTER PIPE 3629101700 PP 1
2 HOLDER HOSE 4569A71021 PP 2
3 RING HOSE 3624600200 PP 1
4 HOSE 3623206300 EVA 1.8M 1
5 CUFF HOSE 3626800200 LDPE 1
6 PIPE HOSE 3624408200 PP 1
7 PACKING HOLE 3624005900 EVA SPONGE 1
8 VALVE AIR 3625400400 PP 1
✔ Caution:
In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
