Daewoo TAC-07HRA/E1 - Page 25

Air Conditioner Service Manual
24
Indoor unit: TAC-07HRA/EW, TAC-09HRA/EW
No.
Part No.
Part Name
Q’ty
Remark
1
1080030003
Installation Plate
1
2
210738613A
Base
1
3
210738389
Vertical Vane Assembly
2
4
210738432
Vertical Vane Connector
1
5
210738127
Vane
1
6
210738131
Cross Fan
1
7
1070100010
Bearing Mount
1
8
211238000
Evaporator
1
9
210738120
Face Frame
1
10
210701846
Screw Cover
2
11
210701863
Air Filter
2
12
210738394
Display PCB Box
1
13
1090250119AM
Display PCB
1
14
210738430A
Front Panel
1
15
210738624A
Display PCB Cover
1
16
1170120044
Power Supply Cord
1
17
210738393
Electrical Box Cover
1
18
210736832
Cable Clamp
1
19
210900376
Terminal
1
20
210901224
Transformer
1
21
210901617N
Main PCB
1
22
210736831
Electrical Box
1
23
210900333
Indoor Sensor Assembly
1
24
1170030047F
Indoor Motor
1
25
210737653
Indoor Motor Cover
1
26
210701902
Step Motor connector
1
27
210900129
Step Motor
1
28
210701906
Step Motor Supporter
1
29
210737091
Drainage Hose
1
30
1170020011
Vane Motor
1
31
210736813
In And Out Pipe Fixer
1
32
210901521B
Remote Controller
1
Not shown in Explosion view
33
211368832G
Indoor Carton
1
34
211368514
Left Foaming
1
35
211368516
Right Foaming
1
