Daewoo TAC-07HRA/E1 - Product Dimensions

Air Conditioner Service Manual
2
3. Product Dimensions
Indoor Unit:
Outdoor Unit:
Model
Indoor unit
Outdoor unit
A
B
C
D
E
F
G
H
I
J
K
TAC-07HRA/E1
698
255
190
600
500
232
375
276
256
52
55
TAC-07HRA/EW
698
255
190
600
500
232
375
276
256
52
55
TAC-09HRA/E1
698
255
190
600
500
232
375
276
256
52
55
TAC-09HRA/EW
698
255
190
600
500
232
375
276
256
52
55
TAC-09HRA/ES
698
255
190
600
500
232
375
276
256
52
55
TAC-12HRA/E1
777
250
205
700
552
256
439.2
302
277.8
48
55
TAC-12HRA/EW
777
250
205
700
552
256
439.2
302
277.8
48
55
TAC-12HRA/ES
777
250
205
700
552
256
439.2
302
277.8
48
55
TAC-18HRA/E1
910
292
205
760
552
256
508
302
277.8
48
55
TAC-18HRA/EW
910
292
205
760
552
256
508
302
277.8
48
55
TAC-24HRA/E1
910
292
205
820
605
300
518
357
329
55
63
TAC-28HRA/E1
1010
315
220
900
650
307
623
399
349
65
63
TAC-36HRA/WE
1460
349
285
900
805
360
675
399
378
50
63
