Daewoo TAC-07HRA/E1 - Page 27

Air Conditioner Service Manual
26
Indoor unit: TAC-18HRA/EW
No.
Part No.
Part Name
Q’ty
Remark
1
1080030021
Installation Plate
1
2
210738660
Base
1
3
210738575
Vertical Vane Assembly
2
4
210738582
Vertical Vane Connector
1
5
210738574
Vane
1
6
1070020024AA
Cross Fan
1
7
1070100010
Bearing Mount
1
8
211237947
Evaporator
1
9
210738663
Face Frame
1
10
210701846
Screw Cover
2
11
210738606
Air Filter
2
12
210738394
Display PCB Box
1
13
1090250119AM
Display PCB
1
14
210738571A
Front Panel
1
15
210738624A
Display PCB Cover
1
16
210738393
Electrical Box Cover
1
17
210736832
Cable Clamp
1
18
210900376
Terminal
1
19
210901224
Transformer
1
20
210901617T
Main PCB
1
21
210736831
Electrical Box
1
22
1170030067J
Indoor Motor
1
23
210738581
Indoor Motor Cover
1
24
210701902
Step Motor connector
1
25
210900129
Step Motor
1
26
210701906
Step Motor Supporter
1
27
210737091
Drainage Hose
1
28
1170020031AC
Vane Motor
1
29
210736813
In And Out Pipe Fixer
1
30
210900333
Indoor Sensor Assembly
1
Not shown in Explosion view
31
210901521B
Remote Controller
1
32
211369420AW
Indoor Carton
1
33
211369459
Left Foaming
1
34
211369460
Right Foaming
1
