Air Conditioner Service Manual
30
Indoor unit: TAC-36HRA/WE
No.
Part No.
Part Name
Q’ty
Remark
1
210826433
Installation Plate
1
2
210826434
In And Out Pipe Fixer
2
3
210735863
Base
1
4
210735759
Cross Fan Supporter
1
5
210735912
Middle Bearing Mount
1
6
210735760
Cross Fan Supporter Cover
1
7
210735861
Cross Fan1
1
210735862
Cross Fan2
1
8
1070100010
Bearing Mount
1
9
1070330006
Bearing Mount Supporter
1
10
211231982
Evaporator
1
11
210735864
Water Drainage Assembly
1
12
210735762
Up Vane
1
13
210735763
Down Vane
1
14
210735870
Face Frame
1
15
210735764
Air Filter
3
16
1070252211
Display PCB Box
1
17
210900913D
Display PCB
1
18
210736370
Front Panel
1
19
210736088
Display PCB
1
20
210735782
Terminal Cover
1
21
210800423
Terminal fixing board
1
22
210900380
Terminal
1
23
1070451081AB
Cable Clamp
1
24
210703528
Electrical Box
1
25
210901109
Main PCB
1
26
210900333
Indoor Sensor Assembly
1
27
210701933
Vertical Vane Connector
2
28
210900522A
Step Motor
1
29
210901111
Vane Motor1
1
30
210901111A
Vane Motor2
1
31
1070110012
Drainage Hose
1
32
210735757
Indoor Motor Supporter
1
33
210901130
Indoor Motor
1
34
210735758
Indoor Motor Cover
1
35
210900414A
Remote Controller
1
Not shown in Explosion view
36
210708230
Remote Controller Supporter
1
37
211339061AZ
Indoor Carton
1
38
211338999
Left Foaming
1
39
211339001
Right Foaming
1
