ASSY MAIN
NO PART NAME PART CODE SPECIFICATION REMARK
M01 CABINET WELD AS PRAWPS0000 7510S COLOR OPTION
M02 HANDLE CABINET 4506J03010 PE-HD COLOR OPTION
M03 COVER BACK 3611416200 T0.4x520x610
M04 TERMINAL BLOCK 3618701900 271-312 OPTION
M05 BRACKET TERMINAL 4505D37002 PP OPTION, T/BLOCK
M06 HARNESS POWER 3612756810 7510MP, T/BLOCK 250-CON. OPTION, T/BLOCK
M07 HARNESS 4505D64081 16/0.26X340 FOR GND. OPTION, T/BLOCK
M08 BASE UNDER 3610387000 PP NON PUMP MODEL
BASE UNDER 3610387010 PP, PUMP PUMP MODEL
M09 CUSHION SPOT 450M712010 PP
M10 CUSHION W/M MOTOR 450M712020 NR
M11 MOTOR WASH 3618949700 AC 110V 60Hz, W1D42ED001 DWM-7510T(P)
3618950800 AC 120V 60Hz, W1D42JD001 DWM-7510A(P)
3618949300 AC 220V 60Hz, W1D42UD101 DWM-7510, L
3618949500 AC 220V~240V 50Hz, W1D42VD101 DWM-7510N(P), M(P)
3618949900 AC 110V/220V 50Hz,
120/240V 60Hz, W1D42GD001
DWM-7510S,D(P)
M12 SPECIAL BOLT 3616003100 M5x35 WASHER
M13 PULLEY MOTOR 4506H12011 ADC-12 60Hz
4509A20022 ADC-10 50Hz
M14 BOLT HEX 7342602011 6B-2 6x20 POINTING MFZN
M15 NUT HEX 7393600011 6N-3-6 MFZN
M16 BELT V 450M700020 M-32
M17 DRAIN PUMP 3619601610 AC 110V 60Hz CON. DWM-7510TP
3619610030 AC 120V 620Hz CON. DWM-7510AP
3618955701 AC 220~240V 50Hz CON. DWM-7510NP,MP
3619603810 AC 110/220V 50Hz CON. DWM-7510DP
M18 RING E 7402003031 ER-3 SKZN PUMP MODEL
M19 FAN COOLING 3611801300 ABS PUMP MODEL
✔ Caution:
In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
