M20 BRACKET PUMP 3610604000 PP(OSUNG SA) PUMP MODEL
M21 UNIT CONDENSER 3618943020
50/25
200VAC CON.
DWM-7510T(P)
3618950600 41.6/20.8uF 200/230VAC CON. DWM-7510A(P)
3618943420
12.5/5.2
400/440VAC CON.
DWM-7510L
3618948300
10.4/5.2
400/440VAC CON.
DWM-7510N(P), M(P)
M22 CAPACITOR WASH 4505E11000
25
x2 200VAC CON.
DWM-7510D(P),DUAL
4509C11020
20.8
x2 200VAC CON.
DWM-7510S,DUAL
M23 CAPACITOR SPIN 4509C11010
20.8
CON.
DWM-7510D(P),S,DUAL
M24 HARNESS
CONDENSER
3612706710 CONNECTOR A, B DUAL VOLTAGE
M25 CORD POWER AS
--
M26 COUPLING DRUM AS 4507K16001 7.5kg
M27 NUT HEX 7393800011 6N-3-8 MFZN
M28 BOLT HEX 7342802011 6B-2 8x20 POINTING MFZN
M29 NUT HEX 7393600011 6N-3-6 MFZN
M30 BOLT HEX 7642602011 6B-2 6x20 POINTING MFZN
M31 BOLT HEX 7341500811 6B-1-5x8 MFZN
M32 SPRING BRAKE 4507K53010 SWC D1.0 ZNB-C
M33 BRAKE FIX PLATE AS 4505C54000 2-WAY
M34 ASSY BRAKE WIRE 3619201802 SUS WIRE + PP
M35 BOLT HEX 7341501611 6B-1-5x16 HS MFZN
M36 MOTOR SPIN 3618949600 AC 110V 60Hz W1D35 EF001 DWM-7510T(P)
3618950700 AC 120V 60Hz WID35JF001 DWM-7510A(P)
3618949200 AC 220V 60Hz W1D35UF001 DWM-7510, L
3618949400 AC 220V~240V 50Hz W1D35VF001 DWM-7510N(P), M(P)
3618950100 AC 110/220V 50Hz W1D35FF002 DWM-7510D(P)
3618950000 AC 120/240V 60Hz W1D35LF002 DWM-7510S
M37 CUSHION MOTOR SPIN 4508D14000 PP
M38 BRACKET MOTOR SPIN 3610604100 SPG T1.4
M39 STOPPER 4506H14020 PEHD
NO PART NAME PART CODE SPECIFICATION REMARK
✔ Caution:
In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
