- 14 -
Service manual WP 895/895F, CP885/885F, CP485F
3 - Alignment instructions
3-1 Microcontroller configuration : Service mode
To switch the TV set into service mode please see instruction below.
1 - Select pr. number 91
2 - Adjust sharpness to minimum and exit all menu.
3 - Quickly press the key sequence : RED - GREEN - menu
To software version is displayed beside the word Service, e.g. “ SERVICE V1.00A”.
To exit SERVICE menu press menu key or Std By key.
3-2 Service mode navigation
Pr Up / Down remote keys : cycle through the service items available.
Vol- / + remote keys : Decrement / Increment the values within range.
0~7 digit keys : Toggle bits 0~7 in option byte
Order Item
Default settingh for wp 895
1 PARABOLA +140
2 HOR WIDTH -1100
3 CORNER -80
4 HOR.PARAL -1
5 V.LINEAR -2
6 EW TRAPEZ -12
7 S CORRECT -15
8 H BOW +100
9 VERT SIZE +145
10 VERT CENT +3939
11 RED GAIN +92
12 GRN GAIN +87
13 BLUE GAIN +95
14 RED BIAS +128
15 GRN BIAS +128
16 HOR CEN 98
17 AGC LEVEL -
18 G2-SCREEN -
19 AFT -
20 OPTION -
21 MAX VOL Not used
