HOR PARAL
H BOW
HOR WIDTH
PARAROLA
3-4-6- Horizontal picture centring
Adjust HOR CEN(Horizontal center) to have the picture in the center of the screen.
3-4-7- Eau/West comection
Adjust the PARABOLA, HOR WIDTH, CORNER, HOR PARAL, EW TRAPEZ, H BOW, to compensate for
geometrical distorrin,
Service manual WP 895/895F, CP885/885F, CP485F
- 17 -
For HOR WIDTH, adjust for 91% overscan.
