- 76 -
LOC PART CODE PART NAME DESCRIPTION REMARK
10000 PTACPW-SWX ACCESSORY AS DWX-_____
11000 48586A1617 INSTRUC. MANUAL ALL
12000 48B4846G22 REMOTE CONTROL R-46G22
13000 4850Q00910 BATTERY "AAA 1,5V (SUPERGARD-PTE)"
14000 4858211400F POLY BAG M/N 350MM BOBINE
20000 PTPKCP28W8 PACKING AS 28W8
21000 4858058900 CARTONBOX 28W5/28W8/W9
22000 4858197300UP PAD UP 28W8/28W9
23000 4858197300DN PAD DOWN 28W8/28W9
24000 4858216202F-02 POLY BAG 25''-28'' PE COEXTRUDE 1650X1270
25000 485580B001F STICKER 115 X 285
26000 4850075990F2 TAPE CLOSING TAPE ( 75 X 990M ) 3739
27000 4850075066F3 TAPE CLOSING TAPE ( 75 X 66M ) 3739
30000 PTFMSJ28W9 FRONT MASK AS 28W9 M.SILVER
31100 4855617401 MARK BRAND AL SILVER (28B1)
32000 48548628-050792 BUTTON POWER 28W9 M.SILVER
32100 4856716000 SPRING SWPA PIE0.5
34000 4855060500 DECO CTRL 28W9 PVC T0.25(LPP)
35000 48519470AS DOOR AS 28W9 DOOR + DECO SENSOR
35100 4857923300 DOOR LOCK "LA701 (KIFCO),MODEL WITH DOOR"
36500 7172401212 SCREW TAPPTITE TT2 TRS 4X12 MFZN BK
37500 7172401212 SCREW TAPPTITE TT2 TRS 4X12 MFZN BK
31000 PTFMSJ28W9F FRONT MASK FINI 28W9 M.SILVER
00010 48520818-33 FRONT MASK 28W9 M.SILVER
00020 485SV128BP PAINT L8341307
40000 PTCRT-28WFVI CRT AS 28'' 16/9 FLAT 50HZ
41000 4859635860 CRT 28'' WIDE FLAT W66EJY011X101
41100 4850706057 CONN AS "ODY-2019 (14""-20""-21""-25""-28"")"
42000 4851902110 CRT GROUND AS 28'' 16/9
43000 58G0000159 DEGAUSSING COIL DC-28FW2 (WP-895F DWF)
44000 4856215402 WASHER RUBBER CR T=2MM
450DN 4856015820 SCREW CRT FIX SWRM+SK5 L=35
450UP 4856015820 SCREW CRT FIX SWRM+SK5 L=35
50000 PTSPSUBM27 SPEAKER AS CP-776
51000 4858311110 SPEAKER "12W 8 OHM SP-58126F 25""28"" X2"
51100 4850704S30 CONN AS YH025-03+35098+ULW=700
52000 4858311110 SPEAKER "12W 8 OHM SP-58126F 25""28"" X2"
60000 PTMPMSWF81P PCB AS DWF-28__ZZP-SUM
62000 4859906310 POWER CORD AS 14-LO+H03VVH2+HOU=2200 UK
63000 4856818300 CLAMP WIRE PH-WL-5034
64000 4856812001 TIE CABLE "NYLON66 DA100,14,20,21,25,28"
61000 PTMPMSWF80PW PCB WITH TUNER DWF-28__ZZP
61100 PSMPMSWF80PW PCB W/O TUNER DWF-28__ZZP
61200 4859722430 TUNER VARACTOR UV1316/AIG-3
61300 2193011101 SOLDER WIRE "RS 60-1.2 1.6A PROD,APF,ROULX"
70000 PTBCSH28W5 BACK COVER AS 28W5
71000 48521589-22 BACK COVER 28W5
73000 7172401612 SCREW TAPPTITE TT2 TRS 4X16MFZN BK
75000 4855415800 SPEC PLATE "150 ART P/E FILM TVCR,HIT"
ZZ290 PTMPMSF28W8ZP PCB MAIN MANUAL AS DWF-28W8ZP
10 2193100801 SOLDER BAR SN:PB=63:37 3PI(NO FLUX)
40 2291050314 FLUX SOLVENT IM-1000
20 2193011101 SOLDER WIRE RS 60-1.2 1.6A
30 2291050617P FLUX SOLDER CF-329D
50 2291140501 WAX COVER 60G/PC
60 2291051001 FLUX KILLER KFT-7
C106 CEXF1H221V C ELECTRO 50V RSS 220MF (10X16) TP
C118 CMXL1J474J C MYLAR 63V 0.47MF MKT
C315 CEXF2A470V C ELECTRO 100V RSS 47MF (10X16) TP
C402 CMYH3C133J C MYLAR 1.6KV 0.013MF J
C408 CMYE2G514J C MYLAR 400V 0.51MF J (PL)
C409 CMYE2G394J C MYLAR 400V PU 0.39MF J
C415 CEXF2E479V C ELECTRO 250V RSS 4.7MF (10X16)TP
C430 CCXB3D681K C CERA 2KV B 680PF K (TAPPING)
C431 CMXM2A103J C MYLAR 100V 0.01MF J (TP)
C440 CMXE2G273J C MYLAR 400V PU 0.027MF J (T
C499 CEYD1H689W C ELECTRO 50V RHD 6.8MF (16X35.5)
C604 CEXF1E102V C ELECTRO 25V RSS 1000MF (13X20) TP
C801 CL1JB3474K C LINE ACROSS AC250V 0.47MF U/C/SNDF/SV
C805 CEYN2G181P C ELECTRO 400V LHS 180MF (25X35)
C811 CCYR3D681K C CERA 2KV R 680PF K 125C
C812 CH1AFE472M C CERA AC 4KV 4700PF M KX DE1610
C813 CEXF2E101V C ELECTRO 250V RSS 100MF 18X35.5
C814 CEYF2E470V C ELECTRO 250V RSS 47MF (16X25
C820 CCYR3A471K C CERA 1KV 470PF K 125C
C823 CEXF1E102V C ELECTRO 25V RSS 1000MF (13X20) TP
C832 CEXF1E102V C ELECTRO 25V RSS 1000MF (13X20) TP
C840 CEXF1C222V C ELECTRO 16V RSS 2200MF(13X25)TP
C841 CEXF1C332V C ELECTRO 16V RSS 3300MF
C861 CEXF1E102C C ELECTRO 25V RUS 1000MF 13X20 TP
C866 CCYR3A471K C CERA 1KV 470PF K 125C
C900 CCXB3D102K C CERA 2KV B 1000 PF K (TAPPING)
C910 CEXF2E479V C ELECTRO 250V RSS 4.7MF (10X16)TP
C997 CEXF2E100V C ELECTRO 250V RSS 10MF (10X20) TP
D403 DBY228---- DIODE BY228
D404 DBYW76---- DIODE BYW76
D820 DBYW76---- DIODE BYW76
D860 DBYW76---- DIODE BYW76
F801 5FSCB4022R FUSE CERA SEMKO F4AH 4A 250V MF51
G900 4SG0D00103 SPARK GAP S-23 900V-1.5KV
I101 1TDA4470M- IC IF TDA4470-M
I301 1TDA8358J- IC VERTICAL TDA8358J
I301A 4857028227 HEAT SINK AL EX ANODIZING
I301B 7174301011 SCREW TAPPTITE TT2 RND 3X10 MFZN
I501 1DW3834AE1 IC MICOM DW3834A-AE1
I601 1MSP3410G- IC SOUND PROCESSOR MSP3410G
I602 1TDA8946J- IC AUDIO TDA8946J
I602A 4857028215 HEAT SINK AL EX NO ANODOZING
I602B 7174301011 SCREW TAPPTITE TT2 RND 3X10 MFZN
I702 1AT24C16PC IC MEMORY AT24C16-10PC
I703 1TSOP1238W IC PREAMP TSOP1238WI1
I801 1STRF6654- IC SMPS STR-F6654
I801A 4857027701 HEAT SINK AL EX
I801B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN
I804 1KP1010C-- IC PHOTO COUPLER KP-1010C
I806 1SE130N--- IC SE130N
I810 TX0202DA-- THYRISTOR X0202DA
I820 1KA7805--- IC REGULATOR KA7805
I822 1KA7808--- IC REGULATOR KA7808
I823 1KA7805--- IC REGULATOR KA7805
I901 1TDA6107Q- IC VIDEO TDA6107Q
I901A 4857031100 HEAT SINK A1050P-H24 T2.0
I901B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN
JP01 4859102130 JACK EARPHONE YSC-1537
JPA1 4859200401 SOCKET RGB SR-21A1 (ANGLE TYPE)
JPA2 4859200401 SOCKET RGB SR-21A1 (ANGLE TYPE)
JPA3 4859108450 JACK PIN BOARD YSC03P-4120-14A
JPA4 4859106740 SVHS JACK PH-SJ-9505A
L150 58E0000041 COIL AFT TRF-A005
L380 58C0000120 COIL CHOKE CH-100Q
L381 58C0000120 COIL CHOKE CH-100Q
L802 58C9430599 COIL CHOKE AZ-9004Y(94MH)
LF801 5PLF24A1-- FILTER LINE LF-24A1
M351 4858900002 HOLDER LED AS LH-3P
P401 4850706N08 CONNECTOR 6PIN 500MM BOARD IN TYPE
P402 4859240120 CONN WAFER YFW500-06
P501 4850705N14 CONNECTOR BIC-05T-25T+ULW=500
P601 4859231720 CONN WAFER YW025-04
P801 4859287320 CONN WAFER MKS2822 (LOMAX NEW TYPE)
P802 4859242220 CONN WAFER YFW800-02
P903 4859238620 CONN WAFER YPW500-02
Q401 T2SD1880-- TR 2SD1880
Q401A 4857024500 HEAT SINK AL EX
Q401B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN
R398 RF01Y828JA R FUSIBLE 1W 0.82 OHM J A
R399 RS02Y569JS R M-OXIDE FILM 2W 5.6 OHM J SMALL
R415 RS02Y102JS R M-OXIDE FILM 2W 1K OHM J SMALL
R450 RS02Y223JS R M-OXIDE FILM 2W 22K OHM J SMALL
R801 DPC7R0M290 POSISTOR 96709 (PHILIPS)
R802 RS02Y753JS R M-OXIDE FILM 2W 75K OHM J SMALL
LOC PART CODE PART NAME DESCRIPTION REMARK
Service Manual WP-895/895F, CP885/885F, CP485F
6. Service Parts List
(TW28D11)
“ “ Parts recommended for stock.
“ “ Safety critical componen, Replace only with genuine Daewoo safety parts.
!
R
R
R
!
!
!
R
R
!
R
R
R
R
R
R
R
R
R
R
R
!
!
!
!
✐ CAUTION:In this Service Manual, some parts can be changed for improving their
performance without notice in the parts list. So, if you need the latest parts
information, please refer to PPL(Parts Price List)in Service information
Center(http://svc.dwe.co.kr)
