Daewoo WP-895 - Page 79

- 78 -
Q599 T2SA1980Y- TR 2SA1980Y
Q601 T2SA1980Y- TR 2SA1980Y
Q701 T2SC5343Y- TR 2SC5343Y
Q702 T2SA1980Y- TR 2SA1980Y
Q807 T2SC5343Y- TR 2SC5343Y
Q808 T2SC5343Y- TR 2SC5343Y
Q809 T2SC5343Y- TR 2SC5343Y
Q810 T2SC5343Y- TR 2SC5343Y
Q811 T2SC5343Y- TR 2SC5343Y
Q850 T2SC5343Y- TR 2SC5343Y
Q851 T2SC5343Y- TR 2SC5343Y
QA1 T2SC5343Y- TR 2SC5343Y
RB10 RV5426103P R SEMI FIXED RH0638C 10K OHM B
SW700 5S50101090 SW TACT SKHV17910A
SW701 5S50101090 SW TACT SKHV17910A
SW702 5S50101090 SW TACT SKHV17910A
SW703 5S50101090 SW TACT SKHV17910A
SW704 5S50101090 SW TACT SKHV17910A
Z601 5PXF1B471M FILTER EMI CFI 06 B 1H 470PF
Z602 5PXF1B471M FILTER EMI CFI 06 B 1H 470PF
Z603 5PXF1B471M FILTER EMI CFI 06 B 1H 470PF
Z604 5PXF1B471M FILTER EMI CFI 06 B 1H 470PF
Z605 5PXF1B471M FILTER EMI CFI 06 B 1H 470PF
Z606 5PXF1B471M FILTER EMI CFI 06 B 1H 470PF
Z607 5PXF1B471M FILTER EMI CFI 06 B 1H 470PF
Z608 5PXF1B471M FILTER EMI CFI 06 B 1H 470PF
ZZ200 PTMPJAF28W8ZP PCB MAIN AXIAL AS DWF-28W8ZZP
20 2TM10006LB TAPE MASKING 3M #232-MAP-C 6.2X2000M
10 2TM14006LB TAPE MASKING 3M #232 6.0X2000M
A001 4859805193 PCB MAIN WP-895F
C101 CCZB1H101K C CERA 50V B 100PF K (AXIAL)
C103 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
C104 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
C116 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z (AXIAL)
C119 CCZF1H103Z C CERA 50V F 0.01MF Z
C120 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
C151 CCZF1H103Z C CERA 50V F 0.01MF Z
C154 CCZF1H103Z C CERA 50V F 0.01MF Z
C160 CCZF1H103Z C CERA 50V F 0.01MF Z
C161 CZSL1H220J C CERA 50V SL 22PF J (AXIAL)
C163 CCZF1H103Z C CERA 50V F 0.01MF Z
C500 CCZF1H103Z C CERA 50V F 0.01MF Z
C501 CCZF1H103Z C CERA 50V F 0.01MF Z
C503 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z (AXIAL)
C505 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
C506 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z (AXIAL)
C507 CCZF1H103Z C CERA 50V F 0.01MF Z
C509 CCZF1H103Z C CERA 50V F 0.01MF Z
C512 CCZF1H103Z C CERA 50V F 0.01MF Z
C516 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
C526 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z (AXIAL)
C527 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
C534 CCZB1H333K C CERA 50V B 0.033MF K (AXIAL)
C535 CCZB1H333K C CERA 50V B 0.033MF K (AXIAL)
C536 CCZB1H333K C CERA 50V B 0.033MF K (AXIAL)
C548 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z (AXIAL)
C554 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z (AXIAL)
C560 CCZB1H101K C CERA 50V B 100PF K (AXIAL)
C561 CCZB1H101K C CERA 50V B 100PF K (AXIAL)
C568 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z (AXIAL)
C571 CCZB1H101K C CERA 50V B 100PF K (AXIAL)
C578 CCZB1H221K C CERA 50V B 220PF K (AXIAL)
C579 CCZB1H221K C CERA 50V B 220PF K (AXIAL)
C581 CCZB1H101K C CERA 50V B 100PF K (AXIAL)
C585 CCZB1H101K C CERA 50V B 100PF K (AXIAL)
C589 CCZB1H221K C CERA 50V B 220PF K (AXIAL)
C590 CZCH1H309C C CERA 50V CH 3PF C (AXIAL)
C591 CZCH1H309C C CERA 50V CH 3PF C (AXIAL)
C601 CCZB1H472K C CERA 50V B 4700PF K (AXIAL)
C603 CCZB1H472K C CERA 50V B 4700PF K (AXIAL)
C620 CZCH1H309C C CERA 50V CH 3PF C (AXIAL)
C621 CZCH1H309C C CERA 50V CH 3PF C (AXIAL)
C631 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z (AXIAL)
C650 CZSL1H680J C CERA 50V SL 68PF J (AXIAL)
C830 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z (AXIAL)
CA1 CCZB1H101K C CERA 50V B 100PF K (AXIAL)
CA10 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
CA13 CCZB1H471K C CERA 50V B 470PF K (AXIAL)
CA14 CCZB1H471K C CERA 50V B 470PF K (AXIAL)
CA15 CCZB1H471K C CERA 50V B 470PF K (AXIAL)
CA16 CCZB1H471K C CERA 50V B 470PF K (AXIAL)
CA17 CCZB1H471K C CERA 50V B 470PF K (AXIAL)
LOC PART CODE PART NAME DESCRIPTION REMARK
CA18 CCZB1H471K C CERA 50V B 470PF K (AXIAL)
CA19 CCZB1H222K C CERA 50V B 2200PF K (AXIAL)
CA2 CCZB1H101K C CERA 50V B 100PF K (AXIAL)
CA20 CCZB1H222K C CERA 50V B 2200PF K (AXIAL)
CA3 CCZB1H101K C CERA 50V B 100PF K (AXIAL)
CA4 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
CA7 CCZB1H471K C CERA 50V B 470PF K (AXIAL)
CA8 CCZB1H471K C CERA 50V B 470PF K (AXIAL)
D100 DUZ33B---- DIODE ZENER UZ-33B
D101 DBAT85---- DIODE BAT85 (TAPPING)
D103 D1SS85TA-- DIODE 1SS85TA
D313 DBYW36---- DIODE BYW36 (TAPPING)
D360 DTZX22C--- DIODE ZENER TZX22C (TAPPING)
D361 DUZ33B---- DIODE ZENER UZ-33B
D362 DUZ33B---- DIODE ZENER UZ-33B
D367 DUZ33B---- DIODE ZENER UZ-33B
D405 DBYW36---- DIODE BYW36 (TAPPING)
D407 DBYW36---- DIODE BYW36 (TAPPING)
D408 DBYW36---- DIODE BYW36 (TAPPING)
D410 D1N4004S-- DIODE 1N4004S
D411 D1N4004S-- DIODE 1N4004S
D450 DBYW36---- DIODE BYW36 (TAPPING)
D520 D1N4148--- DIODE 1N4148 (TAPPING)
D521 D1N4148--- DIODE 1N4148 (TAPPING)
D533 D1N4148--- DIODE 1N4148 (TAPPING)
D534 D1N4148--- DIODE 1N4148 (TAPPING)
D537 D1N4148--- DIODE 1N4148 (TAPPING)
D550 D1N4148--- DIODE 1N4148 (TAPPING)
D551 D1N4148--- DIODE 1N4148 (TAPPING)
D591 DUZ2R7B--- DIODE ZENER UZ-2.7B
D597 D1N4148--- DIODE 1N4148 (TAPPING)
D598 D1N4148--- DIODE 1N4148 (TAPPING)
D599 DTZX5V6B-- DIODE ZENER TZX5V6B (TAPPING)
D601 D1N4148--- DIODE 1N4148 (TAPPING)
D602 D1N4148--- DIODE 1N4148 (TAPPING)
D603 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
D801 DBYT51J--- DIODE BYT51J (TAPPING)
D802 DBYT51J--- DIODE BYT51J (TAPPING)
D803 DBYT51J--- DIODE BYT51J (TAPPING)
D804 DBYT51J--- DIODE BYT51J (TAPPING)
D805 DBYW36---- DIODE BYW36 (TAPPING)
D806 DBYW36---- DIODE BYW36 (TAPPING)
D808 DBYW36---- DIODE BYW36 (TAPPING)
D809 DBYW36---- DIODE BYW36 (TAPPING)
D811 DTZX6V2--- DIODE ZENER TZX6V2B (TAPPING)
D821 DBYW36---- DIODE BYW36 (TAPPING)
D824 D1N4148--- DIODE 1N4148 (TAPPING)
D825 D1N4148--- DIODE 1N4148 (TAPPING)
D830 DBYW36---- DIODE BYW36 (TAPPING)
D831 DBYW36---- DIODE BYW36 (TAPPING)
D840 D1N4148--- DIODE 1N4148 (TAPPING)
D841 D1N4148--- DIODE 1N4148 (TAPPING)
D850 DUZ2R7B--- DIODE ZENER UZ-2.7B
D911 DBAV21---- DIODE BAV21 (TAPPING)
D912 DBAV21---- DIODE BAV21 (TAPPING)
D913 DBAV21---- DIODE BAV21 (TAPPING)
D997 DBYT51J--- DIODE BYT51J (TAPPING)
DA10 DTZX5V6B-- DIODE ZENER TZX5V6B (TAPPING)
DA11 DTZX5V6B-- DIODE ZENER TZX5V6B (TAPPING)
DA15 DTZX5V6B-- DIODE ZENER TZX5V6B (TAPPING)
DA16 DTZX5V6B-- DIODE ZENER TZX5V6B (TAPPING)
DA20 DTZX5V6B-- DIODE ZENER TZX5V6B (TAPPING)
DA27 DTZX5V6B-- DIODE ZENER TZX5V6B (TAPPING)
DA3 DTZX5V1B-- DIODE ZENER TZX5V1B (TAPPING)
DA32 DTZX5V6B-- DIODE ZENER TZX5V6B (TAPPING)
DA6 DTZX5V6B-- DIODE ZENER TZX5V6B (TAPPING)
DA7 DTZX5V1B-- DIODE ZENER TZX5V1B (TAPPING)
DA8 DTZX5V6B-- DIODE ZENER TZX5V6B (TAPPING)
DA9 DTZX5V6B-- DIODE ZENER TZX5V6B (TAPPING)
J001 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J002 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J003 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J005 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J006 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J007 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J008 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J009 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J015 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J016 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J018 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J019 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J022 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
LOC PART CODE PART NAME DESCRIPTION REMARK
Service Manual WP-895/895F, CP885/885F, CP485F
