LOC PART CODE PART NAME DESCRIPTION REMARK
ZZ110 PTACPWB21U7FS ACCESSORY AS DTB-21U7FZF-S
00030 4850Q00910 BATTERY AAA R03/NN SUPERGARD
M751 4857539601 COVER JACK 21U7 ABS GY
M821 4858213801 BAG INSTRUCTION L. D. P. E. T0. 05X250X40
ZZ100 48B4846G22 TRANSMITTER REMOCON R-46G22
ZZ120 PTBCSHB21U7S COVER BACK AS DTB-21U7ZJF-S
M211 4852161901 COVER BACK 21U7 HIPS GY
M541 4855415800 S/PLATE 150ART P/E FILM (C/TV)
M542 4855800022 LABEL SERIAL ART 90 70X19
M781 4857817610 CLOTH BLACK "300 MM 20"" "
ZZ130 PTCACAB21U7FFS CABINET AS DTB-21U7FZF-S
20 2193011101 SOLDER WIRE RS 60-1.2 1.6A
30 2224050001 BOND TB-2507
40 4856812001 TIE CABLE NYLON66 DA100
M191 4851947101 BUTTON CTRL AS 21U7 4952901+5547601
M191A 7178301011 SCREW TAPPING TT2 WAS 3X10 MFZN
M201A 4856013300 SCREW CRT FIXING AS L-80
M201B 4856215402 WASHER RUBBER 20''
M201C 4856013302 SCREW CRT FIXING AS L-190
M211A 7172401612 SCREW TAPPING TT2 TRS 4X16 MFZN BK
M211B 7178301211 SCREW TAPPITE TT2 WAS 3X12 MFZN
M481 4854862501 BUTTON POWER 21U7 ABS GY
M481A 4856716000 SPRING 14Q1/M3 SWPA PIE0.5
M561 48556175SD01 MARK BRAND DAEWOO 21T5 (SILVER)
P402A 4850704N07 CONNECTOR SE100J+172792+USW=500
PWC1 4859906210 CORD POWER W/F 6-LO (LOMAX NEW)
SP01A 7178301011 SCREW TAPPING TT2 WAS 3X10 MFZN
SP02A 7178301011 SCREW TAPPING TT2 WAS 3X10 MFZN
V901 4859637360 "CRT (PHILIPS 21"") " A51ERF135X80 (FLAT)
ZZ131 58G0000147 COIL DEGAUSSING DC-21SF
ZZ132 48519A5210 CRT GROUND AS 21A5
ZZ200 PTFMSJB21U7S MASK FRONT AS DTB-21U7ZJF-S
M801 4852081201 MASK FRONT 21U7 HIPS GY
ZZ210 PTSPPWB21U7FS SPEAKER AS DTB-21U7FZF-S
P601A 4850704S28 CONN AS YH025-04+35089+ULW=600
SP01 4858314910 SPEAKER SP-33129A03
SP02 4858314910 SPEAKER SP-33129A03
ZZ290 PTMPMSB21U7FF PCB MAIN MANUAL AS DTB-21U7FZF-S
10 2193100801 SOLDER BAR SN:PB=63:37 3PI(NO FLUX)
40 2291050314 FLUX SOLVENT IM-1000
20 2193011101 SOLDER WIRE RS 60-1.2 1.6A
30 2291050617P FLUX SOLDER CF-329D
50 2291140501 WAX COVER 60G/PC
60 2291051001 FLUX KILLER KFT-7
C106 CEXF1H221V C ELECTRO 50V RSS 220MF (10X16) TP
C118 CMXL1J474J C MYLAR 63V 0.47MF MKT
C315 CEXF2A470V C ELECTRO 100V RSS 47MF (10X16) TP
C402 CMYH3C622J C MYLAR 1.6KV 6200PF J (BUP)
C408 CMYE2G304J C MYLAR 400V 0.3MF J (PL)
C415 CEXF2E479V C ELECTRO 250V RSS 4.7MF (10X16)TP
C430 CCXB3D681K C CERA 2KV B 680PF K (TAPPING)
C431 CMXM2A103J C MYLAR 100V 0.01MF J (TP)
C604 CEXF1E102V C ELECTRO 25V RSS 1000MF (13X20) TP
C801 CL1UC3474M C LINE ACROSS 0.47MF 1J(UCVSNDF/SV
C805 CEYN2G121P C ELECTRO 400V LHS 120MF
C811 CCYR3D681K C CERA 2KV R 680PF K 125C
C812 CH1BFE472M C CERA AC AC400V 4700PF M U/C/V
C813 CEXF2E101V C ELECTRO 250V RSS 100MF 18X35.5
C814 CEYF2E470V C ELECTRO 250V RSS 47MF (16X25
C820 CCYR3A471K C CERA 1KV 470PF K 125C
C823 CEXF1E102V C ELECTRO 25V RSS 1000MF (13X20) TP
C832 CEXF1E102V C ELECTRO 25V RSS 1000MF (13X20) TP
C840 CEXF1C222V C ELECTRO 16V RSS 2200MF(13X25)TP
C841 CEXF1C332V C ELECTRO 16V RSS 3300MF
C861 CEXF1E102C C ELECTRO 25V RUS 1000MF 13X20 TP
C866 CCYR3A471K C CERA 1KV 470PF K 125C
C900 CCXB3D102K C CERA 2KV B 1000 PF K (TAPPING)
C910 CEXF2E479V C ELECTRO 250V RSS 4.7MF (10X16)TP
C997 CEXF2E100V C ELECTRO 250V RSS 10MF (10X20) TP
D403 DDG3------ DIODE DG3
D820 DRGP30J--- DIODE RGP30J
D860 DRGP30J--- DIODE RGP30J
F801 5FSCB4022R FUSE CERA SEMKO F4AH 4A 250V MF51
G900 4SG0DX0001 SPARK GAP SSG-102-A1 (1.0KV)
I101 1TDA4470M- IC IF TDA4470-M
I301 1TDA8358J- IC VERTICAL TDA8358J
I301A 4857024421 HEAT SINK I602A (CP-385)
I301B 7174301011 SCREW TAPPTITE TT2 RND 3X10 MFZN
I501 1DW3834AE2 IC MICOM DW3834A C4 AE2
I601 1MSP3410V3 IC SOUND MSP3410G-V3
I602 1TDA8944J- IC AUDIO TDA8944J
I602A 4857024421 HEAT SINK I602A (CP-385)
I602B 7174301011 SCREW TAPPTITE TT2 RND 3X10 MFZN
I702 1AT24C16PC IC MEMORY AT24C16-10PC
I703 1TS0P1238W IC PREAMP TSOP1238WI1
I801 1STRF6654- IC SMPS STR-F6654
I801A 4857027701 HEAT SINK AL EX
I801B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN
I804 1KP1010C-- IC PHOTO COUPLER KP-1010C
I806 1SE110N--- IC SE110N
I810 TX0202DA-- THYRISTOR X0202DA
I820 1L7805CV-- IC REGULATOR L7805CV
I822 1L7808CV-- IC REGULATOR L7808CV
I823 1L7805CV-- IC REGULATOR L7805CV
I901 1TDA6107Q- IC VIDEO TDA6107Q
I901A 4857031100 HEAT SINK A1050P-H24 T2.0
I901B 7174300811 SCREW TAPPTITE TT2 RND 3X8 MFZN
JP01 4859102130 JACK EARPHONE YSC-1537
JPA1 4859200401 SOCKET RGB SR-21A1 (ANGLE TYPE)
JPA2 4859200401 SOCKET RGB SR-21A1 (ANGLE TYPE)
JPA3 4859108450 JACK PIN BOARD YSC03P-4120-14A
L150 58E0000041 COIL AFT TRF-A005
L380 58C0000120 COIL CHOKE CH-100Q
L381 58C0000120 COIL CHOKE CH-100Q
L401 58H0000016 COIL H-LINEARITY L-102 (102UH)
L802 58C9430599 COIL CHOKE AZ-9004Y(94MH)
LF801 5PLF24A1-- FILTER LINE LF-24A1
M351 4858900002 HOLDER LED AS LH-3P
M601 4856813600 HOLDER WIRE NYLON 66 DAWH-13NA
P401 4850706N08 CONNECTOR 6PIN 500MM BOARD IN TYPE
P402 4859242420 CONN WAFER YFW800-04
P501 4850705N14 CONNECTOR BIC-05T-25T+ULW=500
P601 4859231720 CONN WAFER YW025-04
P801 4859287320 CONN WAFER MKS2822 (LOMAX NEW TYPE)
P802 4859242220 CONN WAFER YFW800-02
P905 4859262120 CONN WAFER YFW 800-01 A5MODELS
Q401 T2SD2578-- TR 2SD2578
R415 RS02Y102JS R M-OXIDE FILM 2W 1K OHM J SMALL
R450 RS02Y223JS R M-OXIDE FILM 2W 22K OHM J SMALL
R801 DPC7R0M290 POSISTOR 96709 (BC)
R802 RS02Y683JS R M-OXIDE FILM 2W 68K OHM J SMALL
R803 RS02Y473JS R M-OXIDE FILM 2W 47K OHM J SMALL
R804 RF02Y228K- R FUSIBLE 2W 0.22 OHM K
R819 RX10B339JN R CEMENT 10W 3.3 OHM J BENCH 4P
R850 RS02Y309JS R M-OXIDE FILM 2W 3 OHM J SMALL
R888 RD-4Z273J- R CARBON FILM 1/4 27K OHM J
R906 RF01Y209JA R FUSIBLE 1W 2 OHM J A CURVE
SCT1 4859303530 SOCKET CRT PCS629-03C
SF1 5PK3953M-- FILTER SAW K3953M
SF2 5PK9650M-- FILTER SAW K9650M
SW801 5S40101143 SW PUSH PS3-22SP (P.C.B)
T401 50D19A1--- TRANS DRIVE TD-19A1
T402 50H0000240 FBT 1152.7001
T801 50M3934A9- TRANS SMPS 2084.0090
U100 4859722430 TUNER VARACTOR UV1316/AIG-3
X501 5XE20R250E CRYSTAL QUARTZ HC-49/U 20.2500MHZ 30PPM
LOC PART CODE PART NAME DESCRIPTION REMARK
Service manual WP 895/895F, CP885/885F, CP485F
6. Service Parts List
(DTB-21U7)
CAUTION
“ “ Parts recommended for stock.
“ “ Safety critical componen, Replace only with genuine Daewoo safety parts.
!
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
R
!
!
!
!
!
!
!
!
!
