Z607 5PXF1B471M FILTER EMI CFI 06 B 1H 470PF
Z608 5PXF1B471M FILTER EMI CFI 06 B 1H 470PF
ZZ200 PTMPJAB21U7FF PCB MAIN AXIAL AS DTB-21U7FZF-S
20 2TM10006LB TAPE MASKING 3M #232-MAP-C 6.2X2000M
10 2TM14006LB TAPE MASKING 3M #232 6.0X2000M
A001 4859806393 PCB MAIN CP-485F 330X246XT1.6
C101 CCZB1H101K C CERA 50V B 100PF K (AXIAL)
C103 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
C104 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
C116 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z (AXIAL)
C119 CCZF1H103Z C CERA 50V F 0.01MF Z
C120 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
C151 CCZF1H103Z C CERA 50V F 0.01MF Z
C154 CCZF1H103Z C CERA 50V F 0.01MF Z
C160 CCZF1H103Z C CERA 50V F 0.01MF Z
C161 CZSL1H220J C CERA 50V SL 22PF J (AXIAL)
C163 CCZF1H103Z C CERA 50V F 0.01MF Z
C440 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
C500 CCZF1H103Z C CERA 50V F 0.01MF Z
C501 CCZF1H103Z C CERA 50V F 0.01MF Z
C503 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z (AXIAL)
C505 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
C506 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z (AXIAL)
C507 CCZF1H103Z C CERA 50V F 0.01MF Z
C509 CCZF1H103Z C CERA 50V F 0.01MF Z
C512 CCZF1H103Z C CERA 50V F 0.01MF Z
C516 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
C526 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z (AXIAL)
C527 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
C534 CCZB1H333K C CERA 50V B 0.033MF K (AXIAL)
C535 CCZB1H333K C CERA 50V B 0.033MF K (AXIAL)
C536 CCZB1H333K C CERA 50V B 0.033MF K (AXIAL)
C548 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z (AXIAL)
C554 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z (AXIAL)
C560 CCZB1H101K C CERA 50V B 100PF K (AXIAL)
C561 CCZB1H101K C CERA 50V B 100PF K (AXIAL)
C568 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z (AXIAL)
C571 CCZB1H101K C CERA 50V B 100PF K (AXIAL)
C578 CCZB1H221K C CERA 50V B 220PF K (AXIAL)
C579 CCZB1H221K C CERA 50V B 220PF K (AXIAL)
C581 CCZB1H101K C CERA 50V B 100PF K (AXIAL)
C585 CCZB1H101K C CERA 50V B 100PF K (AXIAL)
C589 CCZB1H221K C CERA 50V B 220PF K (AXIAL)
C590 CZCH1H309C C CERA 50V CH 3PF C (AXIAL)
C591 CZCH1H309C C CERA 50V CH 3PF C (AXIAL)
C601 CBZR1C472M C CERA Y5R 16V 4700PF M AXIAL
C603 CBZR1C472M C CERA Y5R 16V 4700PF M AXIAL
C620 CZCH1H309C C CERA 50V CH 3PF C (AXIAL)
C621 CZCH1H309C C CERA 50V CH 3PF C (AXIAL)
C631 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z (AXIAL)
C650 CZSL1H680J C CERA 50V SL 68PF J (AXIAL)
C830 CBZF1H104Z C CERA SEMI 50V F 0.1MF Z (AXIAL)
CA01 CCZB1H101K C CERA 50V B 100PF K (AXIAL)
CA02 CCZB1H101K C CERA 50V B 100PF K (AXIAL)
CA03 CCZB1H101K C CERA 50V B 100PF K (AXIAL)
CA04 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
CA07 CCZB1H471K C CERA 50V B 470PF K (AXIAL)
CA08 CCZB1H471K C CERA 50V B 470PF K (AXIAL)
CA10 CCZB1H102K C CERA 50V B 1000PF K (AXIAL)
CA13 CCZB1H471K C CERA 50V B 470PF K (AXIAL)
CA14 CCZB1H471K C CERA 50V B 470PF K (AXIAL)
CA15 CCZB1H471K C CERA 50V B 470PF K (AXIAL)
CA16 CCZB1H471K C CERA 50V B 470PF K (AXIAL)
CA17 CCZB1H471K C CERA 50V B 470PF K (AXIAL)
CA18 CCZB1H471K C CERA 50V B 470PF K (AXIAL)
CA19 CCZB1H222K C CERA 50V B 2200PF K (AXIAL)
CA20 CCZB1H222K C CERA 50V B 2200PF K (AXIAL)
D100 DUZ33B---- DIODE ZENER UZ-33B
D101 DBAT85---- DIODE BAT85 (TAPPING)
D103 D1SS85TA-- DIODE 1SS85TA
D313 D1N4937G-- DIODE 1N4937G
D360 DTZX22C--- DIODE ZENER TZX22C (TAPPING)
D361 DUZ33B---- DIODE ZENER UZ-33B
D362 DUZ33B---- DIODE ZENER UZ-33B
D367 DUZ33B---- DIODE ZENER UZ-33B
D405 D1N4937G-- DIODE 1N4937G
D407 DRGP15J--- DIODE RGP15J
D408 DRGP15J--- DIODE RGP15J
D410 D1N4004S-- DIODE 1N4004S
D411 D1N4004S-- DIODE 1N4004S
D450 D1N4937G-- DIODE 1N4937G
D520 D1N4148--- DIODE 1N4148 (TAPPING)
LOC PART CODE PART NAME DESCRIPTION REMARK
D521 D1N4148--- DIODE 1N4148 (TAPPING)
D533 D1N4148--- DIODE 1N4148 (TAPPING)
D534 D1N4148--- DIODE 1N4148 (TAPPING)
D537 D1N4148--- DIODE 1N4148 (TAPPING)
D550 D1N4148--- DIODE 1N4148 (TAPPING)
D551 D1N4148--- DIODE 1N4148 (TAPPING)
D591 DUZ2R7B--- DIODE ZENER UZ-2.7B
D597 D1N4148--- DIODE 1N4148 (TAPPING)
D598 D1N4148--- DIODE 1N4148 (TAPPING)
D599 DTZX5V6B-- DIODE ZENER TZX5V6B (TAPPING)
D601 D1N4148--- DIODE 1N4148 (TAPPING)
D602 D1N4148--- DIODE 1N4148 (TAPPING)
D603 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
D801 DLT2A05G-- DIODE LT2A05G
D802 DLT2A05G-- DIODE LT2A05G
D803 DLT2A05G-- DIODE LT2A05G
D804 DLT2A05G-- DIODE LT2A05G
D805 D1N4937G-- DIODE 1N4937G
D806 D1N4937G-- DIODE 1N4937G
D808 D1N4937G-- DIODE 1N4937G
D809 D1N4937G-- DIODE 1N4937G
D811 DTZX6V2--- DIODE ZENER TZX6V2B (TAPPING)
D821 DRGP15J--- DIODE RGP15J
D824 D1N4148--- DIODE 1N4148 (TAPPING)
D825 D1N4148--- DIODE 1N4148 (TAPPING)
D830 D1N4937G-- DIODE 1N4937G
D831 D1N4937G-- DIODE 1N4937G
D840 D1N4148--- DIODE 1N4148 (TAPPING)
D841 D1N4148--- DIODE 1N4148 (TAPPING)
D850 DUZ2R7B--- DIODE ZENER UZ-2.7B
D911 D1N4004S-- DIODE 1N4004S
D912 D1N4004S-- DIODE 1N4004S
D913 D1N4004S-- DIODE 1N4004S
D997 DLT2A05G-- DIODE LT2A05G
DA03 DTZX5V1B-- DIODE ZENER TZX5V1B (TAPPING)
DA06 DTZX5V6B-- DIODE ZENER TZX5V6B (TAPPING)
DA07 DTZX5V1B-- DIODE ZENER TZX5V1B (TAPPING)
DA08 DTZX5V6B-- DIODE ZENER TZX5V6B (TAPPING)
DA09 DTZX5V6B-- DIODE ZENER TZX5V6B (TAPPING)
DA10 DTZX5V6B-- DIODE ZENER TZX5V6B (TAPPING)
DA11 DTZX5V6B-- DIODE ZENER TZX5V6B (TAPPING)
DA15 DTZX5V6B-- DIODE ZENER TZX5V6B (TAPPING)
DA16 DTZX5V6B-- DIODE ZENER TZX5V6B (TAPPING)
DA20 DTZX5V6B-- DIODE ZENER TZX5V6B (TAPPING)
DA27 DTZX5V6B-- DIODE ZENER TZX5V6B (TAPPING)
DA32 DTZX5V6B-- DIODE ZENER TZX5V6B (TAPPING)
J002 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J003 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J005 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J006 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J007 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J008 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J009 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J013 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J015 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J016 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J018 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J019 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J022 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J023 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J024 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J025 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J036 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J038 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J046 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J047 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J053 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J054 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J056 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J057 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J058 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J061 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J065 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J070 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J072 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J073 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J075 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J076 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J079 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J080 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J082 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
J088 85801065GY WIRE COPPER AWG22 1/0.65 TIN COATING
LOC PART CODE PART NAME DESCRIPTION REMARK
Service manual WP 895/895F, CP885/885F, CP485F
