TECHNICAL DATA
3-4
©
200515
Drive shafts, drive and chassis
0
ΛΦ45/55 series
Allison MD3060 automatic gearbox
F36/F48 front axle
Front axles
(1) Retighten after 100 km.
(2) Evenly tighten the two U-bolt nuts alternately.
V300371
2
1
Drain plug (1) 28 Nm
Oil filter cover
attachment bolts (2) 55 Nm
R600520
6 23 1 54
Tightening torque for
brake calliper
attachment bolts 213 Nm
Tightening sequence
for attachment bolts
Hub lock nut 75 Nm
M18 x 1.5 wheel nut
(LF 45 version 6/8 ton GVW) 370 Nm
(1)
M20 x 1.5 wheel nut
(LF 45 version 10/11/12 ton GVW) 485 Nm
(1)
M20 x 1.5 wheel nut
(LF 55 version 13/14/15 ton GVW) 485 Nm
(1)
M22 x 1.5 wheel nut
(LF 55 version 18 ton GVW) 700 Nm
(1)
LF 45 U-bolt nut 215 Nm
(2)
U-bolt nut, LF 55 version 13/14/15 ton GVW 470 Nm
(2)
U-bolt nut, LF 55 version 18 ton GVW 535 Nm
(2)
