Drive shafts, drive and chassis
TECHNICAL DATA
ΛΦ45/55 series
0
Rear axles
(1) Retighten after 100 km.
(2) Evenly tighten the two U-bolt nuts alternately.
1132 rear axle
Differential
Drive shafts
M18 x 1.5 wheel nut
(LF 45 version 6/8 ton GVW) 370 Nm
(1)
M20 x 1.5 wheel nut
(LF 45 version 10/11/12 ton GVW) 485 Nm
(1)
M20 x 1.5 wheel nut
(LF 55 version 13/14/15 ton GVW) 485 Nm
(1)
M22 x 1.5 wheel nut
(LF 55 version 18 ton GVW) 700 Nm
(1)
LF 45 U-bolt nut 470 Nm
(2)
U-bolt nut, LF 55 version 13/14/15 ton GVW 470 Nm
(2)
U-bolt nut, LF 55 version 18 ton GVW 700 Nm
(2)
Filler and drain plugs/hub plugs (Torx) 85 Nm
Locking nut of crown wheel guide bolt 110 Nm
Differential drain plug 54 Nm
5/16" UNF clamping bracket
Tightening torque 38 Nm
Retightening torque 36 Nm
3/8" UNF clamping bracket
Tightening torque 70 Nm
Retightening torque 67 Nm
