Removal and installation
EXPLANATORY NOTES ON THE MAINTENANCE ACTIVITIES
ΛΦ45/55 series
5
8. Fit a new seal (2) in the hub (5).
9. Fit the hub (5) to the axle journal (1).
10. Fit the bearing cage (7).
11. Apply the specified grease to the front of the
bearing cage (7).
12. Install the circlip (8).
13. Fit the lock nut (10). Tighten the lock nut (10)
to the specified torque. See "Technical data".
Rotate the hub (1), while securing the lock
nut (10), to allow the bearings to set.
14. Turn the lock nut (10) back through
approximately 90. It should be possible to fit
the split pin (9).
15. Place a micrometer (A) on the wheel hub (5).
Allow the stylus to rest on the end of the axle
journal (1).
16. Push and pull on the wheel hub (5). Check
the wheel bearing play and compare this with
the specified value. See "Technical data".
17. If necessary, correct the wheel bearing play
by tightening or loosening the lock nut (10).
18. Fit a new split pin (9) in the lock nut (10).
19. Fit the hub cap (11). Attention: the hub cap
must not be filled with grease.
1
2
3
4
5
6
7
8
9
10
11
S7 00 573
5
1
A
10
S7 00 574
