User’s Manual
186
Table 5-45 Face detection parameters
Channel
In the
list, select the channel that you want to configure the
face detection settings.
Only the analog channel 1 supports this function.
Enable Enable or disable the face detection function.
Rule
Click
to draw areas to filter the target.
You can configure two filtering targets (maximum size and minimum size).
When the target is smaller than the minimum size or larger than the
maximum size, no alarms will be activated. The maximum size should be
larger than the minimum size.
Schedule
Define a period during which the detection is active.
For details, see "Setting Motion Detection Period" section in "5.10.4.1
Configuring Motion Detection Settings."
Alarm-out Port
Click
to display setting interface.
Enable alarm activation function. Select the alarm output port(s) to
which the peripheral alarm devices are connected. When an alarm event
occurs, the system links the peripheral alarm devices connected to the
selected output port.
Post-Alarm
Set a length of time for the Device to delay turning off alarm after the
external alarm is cancelled. The value ranges from 0 seconds to 300
seconds. If you enter 0, there will be no delay.
Show Message
Select the
check box to enable a pop-up message in
your local host PC.
Report Alarm
Select the
check box to enable the system to upload the
alarm signal to the network (including alarm center) when an alarm
event occurs.
Send Email
Select the
check box to enable the system to send an email
notification when an alarm event occurs.
To use this function, make sure the email function is enabled in
Main
Menu > NETWORK > Email
.
Record Channel
Select the channel(s) that you want to record. The selected channel(s)
starts recording after an alarm event occurs.
The recording for intelligence event and auto recording function must be
enabled. For details, see "5.1.4.9
Configuring Recorded Video Storage
Schedule" and "5.9.1 Enabling Record Control."
